5
Table 1
Model CUT OUT (range)
F J
24"
20 7 /
16
" (51.9 cm)-
20 3 /
4
" (52.7 cm)
21 13 /
16
" (55.4 cm)-
21 15 /
16
" (55.7 cm)
30"
20 7 /
16
" (51.9 cm)-
20 3 /
4
" (52.7 cm)
29 1 /
2
" (74.9 cm)-
29 5 /
8
" (75.2 cm)
36"
20 7 /
16
" (51.9 cm)-
20 3 /
4
" (52.7 cm)
35 7 /
16
" (90.0 cm)-
35 9 /
16
" (90.3 cm)
NOTE: After you make the countertop cutout, some installations
may require notching down the base cabinet side walls to clear
the cooktop base. T o avoid this modification, use a base cabinet
with sidewalls wider than the cutout.
If cabinet has a drawer, a 5
1 ∕
8
" (13 cm) depth clearance from the
countertop to the top of the drawer (or other obstruction) in base
cabinet is required.
Flush Installation - Frameless
Model X Y
24" 25 13 /
16
" (65.5 cm) 21 7 /
16
" (54.5 cm)
30" 31" (78.7 cm) 21 7 /
16
" (54.5 cm)
36" 36 1 /
2
" (92.7 cm) 21 7 /
16
" (54.5 cm)
Electrical Requirements
If codes permit and a separate ground wire is used, it is
r ecommended that a qualified electrical installer determine that
the ground path and wire gauge are in accordance with local
codes.
Check with a qualified electrical installer if you ar e not sure the
cooktop is properly grounded.
It is not recommended to have a fuse in the neutral or ground
circuit.
Make sure that the electrical connection and wire size are
adequate and in conformance with the National Electrical Code,
ANSI/NFPA 70-latest edition or CSA Standards C22.1-94,
Canadian Electrical Code, Part 1 and C22.2 No.O-M91-latest
edition, and all local codes and ordinances.
A copy of the above code standards can be obtained from:
National Fire Protection Association
1 Batterymarch Park
Quincy, MA 02169-7471
CSA International
8501 East Pleasant Valley Road
Cleveland, OH 44131-5575
1/4 " (6 mm)
1 ³⁄₁₆ " (3 cm)
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Use 8 gauge copper wire.
Electrically ground cooktop.
Failure to follow these instructions can result in death,
fire, or electrical shock.
X
Y
A
Detail A
R8 ± 0.5
R5.5 ± 0.5
Glass radius 6 mm
