4
■
When installing cooktop over an undercounter built-in oven,
do not fasten cooktop to countertop with clamps or seal
cooktop to countertop. This will make the cooktop easier to
remove if future servicing becomes necessary.
■
Use the countertop opening dimensions that are given
with these Installation Instructions. Given dimensions are
minimum clearances and provide 0" (0 cm) clearance.
■
Grounded electrical supply is required. See “Electrical
Requirements” section.
Product Dimensions
Model
A
B
C
24"
21
5
/
16
"
(54.1 cm)
25
5
/
8
" (65 cm)
3
11
/
16
" (9.4 cm)
30"
21
5
/
16
"
(54.1 cm)
30
3
/
4
" (78.2 cm)
3
11
/
16
" (9.4 cm)
36"
21
5
/
16
"
(54.1 cm)
36
5
/
16
" (92.2 cm)
3
11
/
16
" (9.4 cm)
With frame:
Model
A
B
C
30"
KitchenAid
21
11
/
16
"
(55.1 cm)
31
1
/
8
"
(79.1 cm)
3
9
/
16
"
(9.0 cm)
Whirlpool
22"
(55.9 cm)
30
13
/
16
"
(78.2 cm)
3
9
/
16
"
(9.1 cm)
36"
KitchenAid
21
11
/
16
"
(55.1 cm)
36
11
/
16
"
(93.15 cm)
3
9
/
16
"
(9.0 cm)
Whirlpool
-
-
-
Cabinet Dimensions
IMPORTANT:
If installing a range hood or microwave hood
combination above the range, follow the range hood or
microwave hood combination installation instructions for
dimensional clearances above the cooktop surface.
Model
M1
M2
M2 (Flush)
M3
24"
19"
(48.2 cm)
2
9
/
16
"
(6.5 cm)
2
13
/
16
"
(7.1 cm)
13/16"
(2.1 cm)
30" and 36"
26
3
/
4
"
(68 cm)
2
9
/
16
"
(6.5 cm)
2
13
/
16
"
(7.1 cm)
13/16"
(2.1 cm)
C
A
B
D
A
E
I
J
K
G
H
L
C
F
B
M
A. 24" (65 cm) on 24" models, 30" (78.2 cm) on 30" models,
36" (92.2 cm) on 36" models
B. Combustible area above countertop (shown by dashed box above)
C. 30" (78.2 cm) minimum clearance between top of cooktop
platform and bottom of uncovered wood or metal cabinet
(24" [61 cm] minimum clearance if bottom of wood or metal
cabinet is covered by not less than 1/4" [6.4 mm] flame retardant
millboard covered with not less than No. 28 MSG sheet steel,
0.015" [0.04 cm] stainless steel, or 0.024" [0.06 cm] aluminum or
0.020" [0.05 cm] copper)
D. 13" (33.0 cm) recommended upper cabinet depth
E. 2" (5.1 cm)
F. For details see the Table 1
G. 18" (45.7 cm) minimum clearance from upper cabinet to
countertop within minimum horizontal clearances to cooktop
H. Junction box or outlet; 12" (30.5 cm) minimum from bottom of
countertop
I. Junction box or outlet; 10" (25.4 cm) from right-hand side of
cabinet
J. For details see the Table 1
K. 1" (2.5 cm) minimum distance to nearest left and right side
combustible surface above cooktop
L. 1" (2.5 cm) minimum clearance between back wall and countertop
M.
IMPORTANT:
For proper ventilation, provide a vent cut out in
the back of the cabinet per the following illustration. For standard
and flush installation make sure the cut out and its cut out for
ventilation have their center line aligned.
M2
M1
M3
