16½"
(41.9 cm)
a
A Center
Line
STYLE 2 - FRAMED, RECESSED CABINET
IMPORTANT: The microwave must be level. Use a carpenter’s level to make
sure the cabinet bottom is level.
1. Draw a vertical line on the wall at the center of the 24" (61 cm) wide opening.
2. Place the Mounting Plate/Rear Wall Template onto the wall so that the
centerline of the template is aligned with the center line, and the top of the
template is touching the bottom of the cabinet. Tape the template in this
position.
a
3/8" TO EDGE
NOTE: IT IS VERY IMP ORTANT T O READ AND FOLLOW THE DIRECT IONS IN THE INSTAL LATION INSTRUCT IONS BEFORE PROCEED ING WITH TH IS REAR WA LL TEMP LATE. This Rear Wa ll Template se rves to positi on the botto m mounting p late and to locat e the horizon tal exhaust outlet. 1. Use a leve l to check t hat the temp late is position ed accurately. 2. Locate and mark at least o ne stud on t he left or right side of the centerlin e. It is important to use at lea st one wood screw mounte d firmly in a s tud to suppo rt the weigh t of the microw ave. Mark tw o additional, evenly sp aced locations for the supplied toggle bolts . 3. Drill holes in the marked locations. Wh ere there is a stud, dri ll a 3/16" hole for wood scr ews. For hole s that do no t line up with a stud, drill 5/8" holes fo r toggle bolts . DO NOT INS TALL THE M OUNTING P LATE AT THIS TIME . 4. Remove th e template fr om the rear w all. 5. Review the Installation I nstruction bo ok for your installation situation.
Locate and mark holes t o align with holes in the mounting pl ate. IMPORTA NT: LOCATE A T LEAST ONE STUD ON EITH ER SIDE O F
THE CENTER LINE. MARK THE L OCATION FOR 2 AD DITIONAL , EVENLY SPACED TO GGLE BO LTS IN TH E MOUNT ING PLATE AREA.
Locate an d mark hole s to align w ith holes in t he mounting pl ate. IMPORTANT: LOCATE A T LEAST ON E STUD ON EITHE R SIDE OF THE CENT ERLINE. MARK TH E LOCATI ON FOR 2 ADDITION AL, EVENL Y SPACE D TOGGLE BOLTS IN THE MOU NTING PLAT E
AREA.
Trim the re ar wall tem plate along the dotted line.
Trim the re ar wall temp late along t he dotted l ine.
12"
4"
Darle vuelta a la hoja pa ra consultar la versión en E spañol.
b
A
Center Line
B 30" (76.2 cm) to
cooktop
STYLE 3 - RECESSED CABINET WITH FRONT OVERHANG OR
DECORATIVE TRIM
IMPORTANT:
• The microwave must be level. Use a carpenter’s level to make sure the
cabinet bottom is level.
• If a decorative cabinet trim is interfering with the installation and leveling of
the microwave oven, remove the decorative trim.
• If the cabinets have a front overhang, but no back or side overhang, to keep
the microwave level, place the mounting plate so that the distance from the
top of the mounting plate to the cabinet bottom is equal to the distance
from the bottom of the front overhang to the bottom of the cabinet.
8
ENGLISH
