75
1
HP286819
SPIRAL PIN .188 X 1.12
76
2
HP346717
ROLL PIN .375 X 1.00
77
4
HS347600
WASHER, SAE .375
78
4
HS347601
WASHER, FENDER .375 ID x 1.50 OD x .06 THK
79
2
HS407100
WASHER, SPRING .650 ID x .790 OD x .062 THK
80
4
HS-60536
BOLT, BHSC .375-16 x 2.00 BLK ZINC
81
4
HW-60085
WASHER, USS .312 BLK ZINC
82
4
HX-60184
BALL STUD, .312 - 18 UNC x 10 mm
83
2
HX-60671
CAP, PLASTIC 1.25 ID.
84
46
HX570412
BHSCS, 10-24 X .50, SS
85
4
HY662912
SET SCREW, .312 - 18 UNC x .50 WITH LOCTITE
86
4
HY740000
SET
SCREW
87
2
JC700422
BHSCS .375-16 X 1.50
88
9
JC700424
BHSCS .375-16 X 1.75
89
1
JC700434
BHSCS .375-16 X 3.00
90
2
JC702850
SHCS .375-16 UNC X 5.00
91
4
JL340004
HX HD LAG SC .375 X 3.00
92
2
JN714400
NUT, HEX JAM .375-24 UNF
Cybex FT-360S Functional Trainer Owner’s Manual
ITEM QTY
PART
NO.
DESCRIPTION
9101 FT-360S Station
Service
Page 8-4
*
Language Key
1-German 2-French 3-Spanish 4-English 5-Japanese 6-Swedish 8-Russian
93
4
PP040004
BALL STOP
94
4
PP090202
INSERT, PLASTIC 1.50 x 3.00 x 11 GA
95
4
PP660009
INSERT, PLASTIC SLOT
96
2
PR060005
BUMPER, WEIGHT
97
4
PR070003
FOOT PAD, 2.00 x 5.25
98
4
PR070004
FOOT PAD, 3.00 x 5.00
99
1
PU060203
BUMPER
100
2
PW-60615
PULLEY, CABLE, 2.00 OD x 1.0 HUB
101
2
HS760106
WASHER, FLAT, 1.75 X .688 X .140 T
102
2
HY702912
SET SCREW, .375-16 x .50
103
2
9100-207
STABILIZER TUBE
104
2
9101-201
MAIN ROTATION PIVOT
105
2
9101-202
ARM
106
1
9101-598-X* PLACARD
107
1
9101-599-X* PLACARD
108
1
9100-348-X* DECAL, CAUTION
109
1
4605-381-X* DECAL, WARNING
110
4
8500-311-X* DECAL, WARNING
111 1 9101-999-X* OWNERS MANUAL (NOT SHOWN) 112
2
9100-316
GRIP HAND STRAP ASSEMBLY
113
1
11040-790
DECAL, MADE IN USA
ITEM QTY
PART
NO.
DESCRIPTION
