SMART FADE™ Chapter 8 : TECHNICAL SPECIFICATIONS
PAGE 25
8-3. AUDIO INPUTS
7 stereo inputs : Video = Balanced and unbalanced inputs.
Computer = Unbalanced inputs.
Vi = +4 dBm Max.
Zi = 22 k
Ω unbalanced.
Zi = 44 k Ω balanced.
Gain = +6 / -12 dB adjustable.
8-4. DISPLAY OUTPUT (4/5 BNC connectors)
Levels: R, G, B = 0.7 Vp/p.
Sync. : Separate H & V = TTL.
: Composite = TTL.
Impedance: R, G, B, H & V = 75 Ohms.
Format: • If the computer input is selected : the output format is the same as the Computer input
format.
• If a video input is selected : the output format is one of the formats available in the LCD
menu # 2-2.
8-5. AUDIO OUTPUT
2 stereo outputs (Balanced and Unbalanced).
Vo = +4 dBm Max.
Zo = 600
Ω balanced.
Zo = 300 Ω unbalanced.
G = 0 dB nominal, with Master volume.
8-6. REMOTE PORT (DB 9 female connector)
Levels: RS-232.
Data Rate: 9600 Bauds, 8 data bits, 1 stop bit, no parity bit, no flow control.
8-7. ENVIRONMENTAL
Power Supply: Internal CE / UL / CSA / IEC 950 (50 W), universal, automatic.
Input : 100 VAC to 250 VAC ; 50-60 Hz ; I = 1 A Max.
Storage Temperature: -25 °C to +85 °C (-13 °F to + 185 °F).
Operating temperature: 0 °C to 50 °C (32 °F to 122 °F).
Maximum ambient operating temperature: < 40 °C (< 104 °F).
Hygrometry: 10% to 80% (without condensation).
Dimensions: D 300 x W 440 x H 44 mm / D 11.8" x W 17.3" x H 1.74".
W = 480 mm / 19" with the 19" brackets.
Compatible with the 19" rack (height = 1 unit).
Weight: 3.4 kg / 7.48 lbs.
