Chapter 5 : OPERATING MODE SMART FADE™
PAGE 16
5-3. THE SCALER FOLLOW MODE
• SETTINGS
c We recommend to reset the SMART FADE ™ to all of its default values, with the LCD menu # 6-5, before
proceeding.
d Select the output Sync. type which corresponds to your display device (LCD menu # 2-1).
e Set reference sync = no comput with the LCD menu # 2-2.
f Set output rate = video in rate with the LCD menu # 2-4.
g Select an output format with the LCD menu # 2-3.
NOTE: For fixed pixels display devices (DMD, LCD, PLASMA…), always select the output format
corresponding to the native resolution of your display device. Thus, the display device will not have to
scale the image and the result will be better.
• SWITCHING OPERATION: Identical as the SCALER MODE, see chapter 5-2.
• DISPLAY DEVICE ADJUSTMENTS
c Pre-select a video input and display it onto the output.
d Adjust directly the display device itself, using its position and size control parameters.
NOTE: If you used video with different frame rate (i.e : PAL and NTSC), you should adjust your display device
for the both source.
• IMAGE ADJUSTMENTS: Identical as the SEAMLESS MODE, see chapter 5-1.
• AUDIO ADJUSTMENT: Identical as the SEAMLESS MODE, see chapter 5-1.
5-4. SYNCHRONIZATION MODE TABLE
MODES THE SEAMLESS MODE THE SCALER MODE THE SCALER FOLLOW MODE
APPLICATIONS Video and Computer Presentation. Video presentation (without
computer). Video display (improved for
motion picture in PAL / SECAM /
NTSC).
SYNCHRONIZATION
(OUTPUT) Locked on the Reference
Computer (Computer 1 or
Computer 2). Internal Sync. generated by the
SMART FADE™ Locked on the selected video input
(50 Hz if PAL/SECAM, 59.94 Hz
if NTSC).
LCD MENU # 2-2 = COMPUTER X. # 2-3 = NO COMPUT
# 2-4 = INTERNAL RATE # 2-3 = NO COMPUT.
# 2-4 = VIDEO IN RATE.
TRANSITION MODE • Seamless Cut / Fade or Title
between the "referenced" computer
and all the Video inputs.
• Smooth or Fast Cut to Black for
other switching. • All switching with a Smooth or
Fast Cut to Black • All switching with a Smooth or
Fast Cut to Black
OUTPUT FORMATS Identical to the format
of the Reference Computer
(From 640 x 480
up to 1280 x 1024;
31.5 kHz up to 64 kHz / 60Hz) VGA at 60 Hz or 75 Hz
PLASMA 42" at 60 Hz or 72 Hz
SVGA at 60 Hz or 75 Hz
MAC at 66 Hz or 75 Hz
XGA2 at 60 Hz or 75 Hz
PLASMA 50" at 56 Hz or 75 Hz
SXGA at 60 Hz or 75 Hz
D-ILA at 75 Hz (optional) 640 x 480 at 50 or 59.94 Hz
852 x 480 at 50 or 59.94 Hz
800 x 600 at 50 or 59.94 Hz
832 x 624 at 50 or 59.94 Hz
1024 x 768 at 50 or 59.94 Hz
1280 x 768 at 50 or 59.94 Hz
1280 x 1024 at 50 or 59.94 Hz
1365 x 1024 at 50 or 59.94 Hz
(optional)
