Chapter 7 : LCD FUNCTIONS DESCRIPTION SMART FADE™
PAGE 20
2 [OUTPUT MENU] + ENTER.
2-1 [output sync] + ENTER.
Select the Output Sync. type with LCD CONTROL + ENTER.
• [H&V] = H & V Separate Sync.
• [COMP] = Composite Sync.
2-2 [reference sync] + ENTER.
Select the Reference Sync. with LCD CONTROL + ENTER.
• [COMPUTER 1] = SMART FADE ™ is in Seamless mode. The output is synchronized on Computer 1.
• [COMPUTER 2] = SMART FADE ™ is in Seamless mode. The output is synchronized on Computer 2.
• [NO COMPUT] = Scaler mode (not Seamless) then the LCD menu displays a list of output formats.
Select an output format with LCD CONTROL + ENTER.
NOTE : If a SMART SWITCH VIDEO ™ is connected to the SMART FADE ™, the LCD window displays :
• [COMPUTER 1] = SMART FADE ™ is in Seamless mode. The output is synchronized on Computer 1.
• [COMPUTER 2] = SMART FADE ™ is in Seamless mode. The output is synchronized on Computer 2.
• [COMPUTER 3] = SMART FADE ™ is in Seamless mode. The output is synchronized on Computer 3.
• [EXTEND PC 2] = SMART FADE ™ is in Seamless mode. The output is synchronized on EXTEND PC 2.
• [NO COMPUT] = Scaler mode (not seamless) then the LCD Menu displays a list of output formats.
2-3 [output format] + ENTER.
• If [reference sync] = [COMPUTER 1], [COMPUTER 2], [COMPUTER 3] or [EXTEND PC 2], the LCD
window displays the "referenced" computer input.
• If [reference sync] = [NO COMPUT], the LCD window displays a list of output format, then select an output
format with LCD CONTROL + ENTER.
NOTE: For fixed pixels display devices (DMD, LCD, PLASMA…), always select the output format corresponding
to the native resolution of the display device. Thus, the display device will not have to scale the image and
the result will be better.
2-4 [output rate] + ENTER.
• If [reference sync] = [COMPUTER 1], [COMPUTER 2], [COMPUTER 3], [EXTEND PC 2], the LCD window
displays the computer status.
• If [reference sync] = [NO COMPUT] selected, select an item with LCD CONTROL + ENTER.
• [internal rate] = Output Frame Rate = 60Hz or 75Hz depending of the selected format.
• [video in rate] = Output Frame Rate is identical to the Video Input Rate (50 Hz frame
rate if video input is PAL / SECAM / 625L or 59.94 Hz if video input is
NTSC / 525L).
2-5 [output status] + ENTER.
• [COMP] = Composite Sync. or [H&V] = H&V Separate Sync.
• [SXGA] = Name of the Output Format.
• [64.0K / 60Hz] = Output Line Frequency / Output Frame Frequency (kHz / Hz).
