SMART FADE™ Chapter 7 : LCD FUNCTIONS DESCRIPTION
PAGE 23
6 [CONTROL MENU] + ENTER.
6-1 [languages] + ENTER.
6-2 [key locking] + ENTER.
Select which locking function you need with LCD CONTROL + ENTER.
• [all unlock] = All front panel switches are unlocked.
• [all lock] = All front panel switches are locked.
6-3 [extend switch] + ENTER.
Select this function if you use a SMART SWITCH VIDEO
™ (SMV415) and/or a SMART SWITCH AUDIO ™
(SMA415) connected to your SMART FADE ™ .
• [NO] = No SMART SWITCH connected to the SMART FADE ™ .
• [YES] = SMART SWITCH connected to the SMART FADE ™ .
6-4 [version] + ENTER.
Status of the internal firmware :
K = xxxx L = xxxx R = xxxx V = xxxx
6-5 [default value] + ENTER.
• [NO] = No Adjustments and Settings are modified.
• [YES] = Clears the following Adjustments and sets them to the Factory Setting.
1-1 VIDEO STANDARD = Automatic detection of PAL / NTSC / SECAM / B&W.
1-3 RGB / YUV IN = YUV (Component).
2-1 OUTPUT SYNC = H & V Separate Sync.
2-2 REFERENCE SYNC = Computer 1.
2-3 OUTPUT FORMAT = XGA (1024 x 768 : 48KHz / 60Hz if no computer detected on the
Computer 1 Input).
2-4 OUTPUT RATE = Internal Rate (Active only if "no computer" is selected in 2-2).
3-5 U / OVER SCAN = UNDERSCAN.
3-6 ASPECT RATIO = 4/3.
4-1 FADING EFFECT = 3 seconds.
4-2 TITLE EFFECT = 5 seconds.
4-3-1 VIDEO SWITCH = SMOOTH.
4-3-2 BLACK DELAY = SHORT.
5-1
MASTER VOLUME = 181.
5-2 AUDIO LEVEL = 181.
5-3 AUDIO SOURCE = AUTO (FOLLOW).
6-3 EXTEND SWITCH = NO.
BLACK = ON.
MUTE = ON.
EFFECT = CUT.
7 [FREEZE] + ENTER.
Select an item with LCD CONTROL + ENTER.
• FREEZE [YES] = Freezes the displayed image.
• UNFREEZE [YES] = Unfreezes the displayed image.
NOTE : The FREEZE function is active only on the TV video inputs.
