GRAPHIC SWITCHER II™ Chapter 10 : RS-232 PROGRAMMER'S GUIDE (continued)
PAGE 37
10-4. COMMANDS AND RESPONSES TABLE (continued)
ASCII
COMMAND
VALUE
COMMAND RESPONSE
DESCRIPTION
TYPE MIN MAX
DESCRIPTION
STATUS COMMANDS
U
UNIT
Measures unity in kHz.
Rd
0
65535
IL
ILD
Horizontal period of input signal (M)
Rd
0
65535 Please see value description (next section).
il
ild
Horizontal period of input signal (P)
Rd
0
65535 Please see value description (next section).
ID
IFD
Vertical period of input signal (M)
Rd
0
65535 Please see value description (next section).
id
ifd
Vertical period of input signal (P)
Rd
0
65535 Please see value description (next section).
IP
IPS
Input Sync. detection (MAIN).
Rd
0
1
0 = no Sync. detected
1 = Sync. detected.
ip
ips
Input Sync. detection (PREVIEW).
Rd
0
1
0 = no Sync. detected
1 = Sync. detected.
IH
IHP
Sign of the horizontal input Sync. (M) Rd
0
1
0 = negative
1 = positive.
ih
ihp
Sign of the horizontal input Sync. (P)
Rd
0
1
0 = negative
1 = positive.
IV
IVP
Sign of the vertical input Sync. (M)
Rd
0
1
0 = negative
1 = positive.
iv
ivp
Sign of the vertical input Sync. (P)
Rd
0
1
0 = negative
1 = positive.
IK
IST
Input Sync type detection (MAIN).
Rd
0
3
0 = Separate H &V sync.
1 = Composite sync. (TTL).
2 = SOG (Sync. On Green).
3 = Composite sync. (analog).
ik
ist
Input Sync type detection (PREVIEW). Rd
0
3
Identical as IK command.
II
IIN
Interlaced signal detection (MAIN).
Rd
0
1
0 = not interlaced
1 = interlaced.
ii
iin
Interlaced signal detection (P).
Rd
0
1
0 = not interlaced
1 = interlaced.
IO
IOO
"Out of range" signal detection (M).
Rd
0
1
0 = In range
1 = Out of range.
io
ioo
"Out of range" signal detection (P).
Rd
0
1
0 = In range
1 = Out of range.
IF
IFA
Standard input signal detection (M).
Rd
0
27
Please see value description (next section).
if
ifa
Standard input signal detection (P).
Rd
0
27
Please see value description (next section).
XR
REFR
Input synchronization selection.
Rd/Wr
0
21
0 = Internal rate
17 = S.VIDEO1 rate.
1 = RGB/YUV1 rate.
21 = SDI input rate.
9 = COMPOSITE 9 rate.
XA
REFA
Synchronized input status.
Rd
0
21
Identical as XR command.
XF
REFF
Standard of the referenced input.
Rd
0
27
Please see value description (next section).
XT
REFT
Frame frequency of the referenced
input.
Rd
0
65535 Value in Hz.
CONTROLS COMMANDS
yl
LOCK
FRONT PANEL locking.
Rd/Wr
0
31
1 = locks the INPUT SELECT keys.
2 = locks the ADJUST buttons.
4 = locks the EFFECT keys.
8 = locks the CONTROL keys.
16 = lock the FREEZE keys.
yc
EPOS
Erase all memories.
Rd/Wr
0
1
1 = erase all memories (automatic reset).
yd
DEMO
Demo mode.
Rd/Wr
0
1
0 = demo mode inactive.
1 = demo mode active.
xi
I
Identification number.
Rd
0
65535
xk
K_
"K" Firmware Version.
Rd
0
65535
xx
X_
"X" Firmware Version.
Rd
0
65535
xy
Y_
"Y" Firmware Version.
Rd
0
65535
xs
S_
"S" Firmware Version.
Rd
0
65535
xd
D_
"D" Firmware Version.
Rd
0
65535
xa
A_
"A" Firmware Version.
Rd
0
65535
xb
B_
"B" Firmware Version.
Rd
0
65535
Values displayed in hexadecimal in the
GSW2811R.
Y
FRES
DEFAULT VALUE.
Rd/Wr
0
1
1 = Default value action (automatic reset).
OTHERS COMMANDS
L
CUT
CUT effect.
Rd/Wr
0
1
1 = CUT action (automatic reset).
N
TBP
T-BAR position.
Rd/Wr
0
255
@
@
Percentage of the executed effect.
Rd
0
16383 0 = 0%
16383 = 100%
ua
TBA
T-BAR availability.
Rd
0
1
0 = T-BAR unavailable. 1 = T-BAR available.
?
DEV
Device type.
Rd
0
65535 12 = GSW2811R/GSE2811R.
#
DEV12
Send all device parameters.
Rd
