GRAPHIC SWITCHER II™ Chapter 7 : LCD FUNCTIONS DESCRIPTION (continued)
PAGE 27
5 [CONTROL MENU]
5-1 [languages]
5-2 [key locking] + ENTER.
Select which locking function you need with  + ENTER.
• [input] = Lock or unlock the input keys.
• [adjust] = Lock or unlock the adjust functions.
• [effects] = Lock or unlock the effect key.
• [control] = Lock or unlock the LCD control key.
• [freeze] = Lock or unlock the FREEZE keys.
NOTE: To unlock the control key, pushes simultaneously on ENTER and EXIT.
5-3[key brightness] + ENTER.
Select the level of the key brightness with  + ENTER.
5-4 [erase all mem] + ENTER.
This function allows erasing all the NON-volatile image memories. Select
[YES] and validate with ENTER.
5-5[demo mode] + ENTER.
This mode allows playing a sequence of effect every 4 seconds. Select [YES] and validate with ENTER.
5-6 [versions] + ENTER.
Display the status of the internal firmware.
• A = xxxx • B = xxxx • X = xxxx • Y = xxxx • S = xxxx
• D = xxxx • K = xxxx • V = xxxx (optional) • I = Identification number.
5-7 [default value] + ENTER.
This function allows setting all the image parameters to the factory settings. Select [YES] and validate with ENTER.
Then switch OFF and ON the device.
FUNCTION POSITION FUNCTION POSITION
1-2 RGB/YUV inputs computer HV/C 2-8 test pattern OFF (main and preview).
1-3 video standard auto 2-9-1 video standard NTSC.
1-4 used Inputs used 2-9-2 output rate internal.
1-5 H Sync Load Hi-Z 2-9-3 flicker adjustment 0.
1-6 CV/SV mode 4 CV + 2 SV 2-9-4 U/Overscan Over scan.
2-1 output format XGA 60Hz 4-1 effect 1 key cut
2-2 output rate internal rate 4-2 effect 2 key fading 3.0s
2-4 output sync separate H & V 4-3 effect 3 key hold. title man.
2-5 type of screen screen 4/3 4-4 effect 4 key diamond in 3.0s
tally 1 = RGB/YUV 1 5-2 key locking OFF
tally 2 = compos. 9 5-3 key brightness 3
tally 3 = s.video 1
2-6 tally
tally 4 = SDI.
