GRAPHIC SWITCHER II™
PAGE 29
Chapter 9 : CONTROL SOFTWARE
9-1. CONNECTION
• CONNECTING THE RS-232
Connect the serial port of your controlling device to the REMOTE RS-232 connector of the GRAPHIC SWITCHER II ™
with a straight cable (DB9 pins female / DB9 pins male).
• PIN-OUT
PIN # FUNCTION
2 TRANSMIT DATA (Tx)
3 RECEIVE DATA (Rx)
5 GROUND (Gnd)
DB 9 female connector
(Rear panel of the GRAPHIC SWITCHER II ™ )
• SPEED TRANSMISSION : 9600 bauds, 8 data bits, 1 stop bit, no parity bit, no flow control.
9-2. "GRAPHIC SWITCHER II ™ CONTROL PANEL" SOFTWARE
Your GRAPHIC SWITCHER II ™ is shipped with a WINDOWS 95/98/2000/Me/XP compatible "GRAPHIC SWITCHER
II ™ REMOTE CONTROL" software (3.5" disk). This software allows you to control and make adjustments by a simple
mouse click (output format, image adjustments, etc...).
• SOFTWARE INSTALLATION:
c Turn your computer ON and wait for WINDOWS to completely start.
d Insert the disk into the floppy drive.
e In the WINDOWS START menu, click on RUN.
f Choose the disk drive and click on setup.exe (ex : A:\setup.exe if disk 3.5" is drive A).
g Follow the WINDOWS installation instructions. WINDOWS will create a file C:\Programfiles\ANALOGWAY\
Graphic switcher II remote control.
• STARTING UP:
c Connect the RS-232 cables between the controlling device and the GRAPHIC SWITCHER II
™ as indicated in
section 9-1.
d Then only power ON all of the devices.
e Click on the program files GSW2811 in Start-program-ANALOGWAY-GRAPHIC SWITCHER II to run the
software.
f Click on Control menu and select the Serial port.
The GRAPHIC SWITCHER II ™ is now controllable by the computer.
