Page 21
VIO1600 & ULTRA VIO
Chapter 4 : FRONT PANEL DISPLAY MENUS DESCRIPTION (continued)
PAGE 21
4-5. FUNCTIONS DESCRIPTION (continued)
3
[IMAGE] + ENTER.
NOTE: The image menu contents will be different in case of input & output type selected.
3-1
[centering] + ENTER.
Adjust automatically the image in the centering pattern.
3-2
[pos. settings] + ENTER.
Select one of the following function with + ENTER.
3-2-1
[H position] + ENTER.
Adjust the Horizontal position with + ENTER.
3-2-2
[V position] + ENTER.
Adjust the Vertical position with + ENTER.
3-2-3
[H size] + ENTER.
Adjust the Horizontal size with + ENTER.
3-2-4
[V size] + ENTER.
Adjust the Vertical size with + ENTER.
3-3
[aspect in] + ENTER.
Select the Aspect Ratio of your input source with + ENTER.
• [4/3 standard]: 4/3 input format.
• [16/9 letterbox]: Letterbox input format.
• [WS anamorphic]: Widescreen Anamorphic input format (video) or 16/9 input format (computer).
3-4
[aspect out] + ENTER.
Select one of the following output aspect ratio with + ENTER.
• [standard]: The entire image and the aspect ratio are preserved.
• [crop]: The image is zoomed without deformation to fill the screen, but some borders of the image will be
cropped. The aspect ratio is preserved.
• [full screen]: The image is stretched to fill the screen. The aspect ratio is not preserved.
• [custom]: The image can be zoomed, cropped and stretched at your convenience.
• If the selected input is a VIDEO signal the IMAGE MENU displays the following items:
3-5
[brightness] + ENTER.
Adjust the brightness with + ENTER.
3-6
[contrast] + ENTER.
Adjust the contrast with + ENTER.
3-7
[color] + ENTER.
Adjust the color with + ENTER.
3-8
[hue] + ENTER.
Adjust the tint of the picture (NTSC only) with + ENTER.
3-9
[u / over scan] + ENTER.
Select Underscan or Overscan with + ENTER.
• [underscan]: Underscan mode. The entire image is visible on the screen. Computer mode is underscan.
• [overscan]: Overscan mode. The image is displayed about 8 % bigger than in underscan mode, to avoid seeing
the corners and the borders. Standard TV display mode is overscan.
3-10
[preset] + ENTER.
This function allows setting all the image parameters to the factory settings. Select [YES] and validate with
ENTER.
