Chapter 4 : FRONT PANEL DISPLAY MENUS DESCRIPTION (continued) VIO1600 & ULTRA VIO
PAGE 20
4-5. FUNCTIONS DESCRIPTION (continued)
2 [OUTPUT] + ENTER.
2-1 [output type] + ENTER.
Select one of the following output type with  + ENTER.
2-1-1
[SDTV]: Standard TV/VIDEO output type.
2-1-2 [HDTV]: HDTV output type.
2-1-3 [Computer]: Analog computer output type.
2-1-4 [DVI]: Digital computer output type (DVI).
2-1-5 [SDI/HDSDI]: SDI & HDSDI output type. (ULTRA VIO only)
2-2 [output format] + ENTER.
• If output type = SDTV: Select one of the following SDTV format with  + ENTER.
• [SDTV Composite] • [SDTV RGBS TTL]
• [SDTV S.VIDEO] • [SDTV RGB SOG]
• [SDTV YUV]
• If output type = HDTV: Select one of the following HDTV format with  + ENTER.
• [HDTV 480p]: 853 x 480 at 60 Hz. • [HDTV 720p]: 1280 x 720 at 60 Hz.
• If output type = SDI/HDSDI: Select one of the following format with  + ENTER.
• [480i / NTSC] : SDI format. • [720p]: HDSDI format.
• [576i / PAL] : SDI format. • [1080i]: HDSDI format.
• If output type = Computer or DVI: Select one of the following Computer format with  + ENTER.
• [640x480] • [1280x768]
• [852x480] • [1365x768]
• [800x600] • [1280x1024]
• [1280x720] • [1400x1050]
• [1024x768] • [1600x1200]
2-3 [output rate] + ENTER.
Select one of the following output rate with  + ENTER.
• [PAL / 50Hz]: PAL output standard or 50 Hz output frame rate. Available only if output type = SDTV.
• [NTSC / 60Hz]: NTSC output standard or 60 Hz output frame rate. Available only if output type = SDTV.
• [50Hz]: 50 Hz output frame rate. Available only if output type = HDTV or HDSDI.
• [59.94Hz]: 59.94 Hz output frame rate. Available only if output type = HDTV or HDSDI.
• [60Hz]: 60 Hz output frame rate. Available only if output type = HDTV or HDSDI.
• [internal 50Hz]: 50 Hz output frame rate. Available only if output type = computer or DVI.
• [internal 60Hz]: 60 Hz output frame rate. Available only if output type = computer or DVI.
• [internal 72Hz]: 72 Hz output frame rate. Available only if output type = computer or DVI.
• [internal 75Hz]: 75 Hz output frame rate. Available only if output type = computer or DVI.
• [follow input 1]: The output rate is identical to the input frame rate. The output rate is 50 Hz for PAL &
SECAM video inputs, or 59.94 Hz for NTSC video inputs.
• [genlock SDTV]: The output is genlocked on the SDTV signal connected to the genlock input .
• [genlock HDTV]: The output is genlocked on the HDTV signal connected to the genlock input .
2-4 [output sync] + ENTER.
Select the Output Sync. type with  + ENTER. Available only if output type = Computer.
• [H&V]: H & V Separate Sync.
• [COMP]: Composite Sync.
• [SOG]: Sync On green.
2-5 [test pattern] + ENTER.
Select an item with  + ENTER.
• [no pattern]: No test pattern is displayed.
• [centering]: Displays onto the output a centering pattern (for position and size adjustments).
• [color bar]: Displays onto the output a color bar pattern.
• [grey scale]: Displays onto the output a grey scale pattern.
• [grid]: Displays onto the output a grid pattern.
• [burst]: Displays onto the output a burst pattern.
