VIO1600 & ULTRA VIO Chapter 4 : FRONT PANEL DISPLAY MENUS DESCRIPTION (continued)
PAGE 19
4-5. FUNCTIONS DESCRIPTION
1 [INPUT] + ENTER.
1-1 [input type] + ENTER.
c Select an input with  + ENTER.
d Select the input signal type with + ENTER between:
• [Computer HV/C]
• [Computer SOG]
• [Computer DVI]
• [SDTV Composite]
• [SDTV S.VIDEO]
• [SDTV YUV]
• [SDTV RGBS TTL]
• [SDTV RGB SOG]
• [SDTV RGBS ana.]
• [SDTV SDI]
• [HDTV YUV]
• [HDTV SDI]
• [Audio only]: select this function if you only want to connect an audio source (no video signal needed).
e Then for [SDTV Composite] and [SDTV S.VIDEO], select the video standard with  + ENTER between:
• [NTSC / PAL / SECAM]: automatic NTSC, PAL and SECAM standard detection.
• [NTSC]: NTSC standard detection only.
• [PAL]: PAL standard detection only.
• [SECAM]: SECAM standard detection only.
• [B & W 50/60 Hz]: Black and White detection.
1-2 [used input] + ENTER.
Select an input and then select an item  + ENTER between:
• [used]: A signal is connected to the input.
• [unused]: No signal is connected to the input. The input is unused.
1-3 [H sync load] + ENTER.
Select for each input the load of the H Sync. with  + ENTER.
1-4 [VCR mode] + ENTER.
This function allows improving the image contour of low quality VHS tapes. Select [on] with ENTER.
1-5 [genlock H. ph] + ENTER. (ULTRA VIO only)
This function allows adjusting the genlock horizontal phase. Adjust with  + ENTER.
1-6 [genlock Sc. ph] + ENTER. (ULTRA VIO only)
This function allows adjusting the genlock Subcarrier phase. Adjust with  + ENTER.
1-7 [genlock load] + ENTER. (ULTRA VIO only)
Select the load of the genlock input signal with  + ENTER.
1-8 [input status] + ENTER.
Indicates the status of the selected input.
