Di-VentiX™ Chapter 7 : TECHNICAL SPECIFICATIONS (continued)
PAGE 65
7-1. COMPUTER & VIDEO INPUTS (continued)
• COMPOSITE VIDEO:
Connectors: BNC female (inputs #1 to #4) or HD15 female (inputs #5 to #8).
Standard: PAL / SECAM: 15.625 kHz - 50 Hz - 625 lines.
NTSC (3.58 MHz / 4.43 MHz): 15.734 kHz - 60 Hz - 525 lines.
Level: 1 Vp/p (0.7 V Luma + 0.3 V Sync.).
Impedance: 75 ohms.
• DIGITAL COMPUTER (DVI) INPUT:
Connector: DVI-I female.
Format: Digital Visual Interface (DVI)-TMDS single link.
Resolution: Up to 1600 x 1200 @ 60Hz BR (reduced blanking).
• SD-SDI:
Connector: BNC female.
Data rate: 270 Mbps serial digital.
Impedance: 75 ohms.
• HD-SDI:
Connector: BNC female.
Formats: 720p @ 50 & 59.94 Hz
1080i @ 50 & 59.94 Hz
1080p @ 23.97; 25 & 29.97 Hz.
1080sF @ 23.97 & 25 Hz.
Data rate: 1.5 Gbps serial digital.
Impedance: 75 ohms.
• HD15 PIN ASSIGNMENT
SIGNAL COMPUTER (analog) RGB/S VIDEO SD-YUV & HD-YUV S.VIDEO (Y/C) COMPOSITE VIDEO
PIN 1 RED. RED. Cr / Pr. C (chrominance).
PIN 2 GREEN. GREEN. Y. Y (luminance). VIDEO (NTSC, PAL...)
PIN 3 BLUE. BLUE. Cb / Pb.
PIN 6 RED return. RED return. Cr / Pr return. C return.
PIN 7 GREEN return. GREEN return. Y return. Y return. return.
PIN 8 BLUE return. BLUE return. Cb / Pb return.
PIN 10 GND. GND.
PIN 13 H sync or C sync (S). C sync (S).
PIN 14 V sync.
HD15 female connector of the device.
5
6
1
15
10
11
