A-4: COMMANDS AND RESPONSES TABLE A-4: TABLE DES COMMANDES ET RÉPONSES
COMMAND RESPONSE
COMMAND DESCRIPTION VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX DESCRIPTION
SELECTION COMMANDS / COMMANDES DE SÉLECTION
MM MTRX Switching mode selection. Rd/Wr 0 1 0 = mixer mode 1 = matrix mode
CC CH MAIN selected input. Rd 0 8
CN CHN
• Background switching during a PIP
(in MIXER mode).
• Input pre-selection for OUTPUT 1
(in MATRIX mode).
Rd/Wr 0 8
cc ch PREVIEW selected input (read only). Rd 0 8
cn chn
• Input pre-selection & PIP switching
(in MIXER mode).
• Input pre-selection for OUTPUT 2
(in MATRIX mode).
Rd/Wr 0 8
0 = black
1 = input #1
2 = input #2
3 = input #3
4 = input #4
5 = input #5
6 = input #6
7 = input #7
8 = input #8
G TAKE TAKE (transition). Rd/Wr 0 1
1 = start the transition (automatic reset at the
end of the effect duration).
0 = stop the transition (for holding effect).
ut TKEV Transition availability. Rd 0 1 1 = New input ready to commute.
Z FRZ FREEZE MAIN. Rd/Wr 0 1 0 = inactive 1 = active.
z frz FREEZE PREVIEW. Rd/Wr 0 1 0 = inactive 1 = active.
INPUT COMMANDS / COMMANDES D'ENTRÉE
PC PCH Input selection for adjustment. Rd/Wr 0 8 0 = all inputs. 1 = input #1.... 8 = input #8
PE PEN Input disabling (works with PC) Rd/Wr 0 1 0 = disable 1 = enable.
PL PLD H sync load selection (works with PC). Rd/Wr 0 1 0 = Hi-Z load 1 = 75Ω load.
PR PRGB
RGB input type selection (works with
PC command).
Rd/Wr 0 13
0 = composite 1 = S.VIDEO
2 = YUV 3 = RGBS (TTL)
4 = RGsB (SOG) 5 = RGBS (ana)
6 = SDTV SDI 1 7 = computer (SOG)
8 = comp (HV or C.) 9 = comp DVI
10 = HDTV
11 = HDSDI 1
12 = HDSDI 2 13 = SDTV SDI 2
PI PSTD
Input standard selection (works with
PC command).
Rd/Wr 0 4
0 = NTSC/PAL/SECAM.
1 = NTSC.
2 = PAL.
3 = SECAM 4 = Black & White.
PP PPRC VCR mode Rd/Wr 0 1 0 = OFF 1 = ON.
NOTE: (M) = MAIN output (sortie MAIN). Rd/Wr = Read and write command / Commande de lecture et d'écriture.
(P) = PREVIEW output (sortie PREVIEW). Rd = Read only command / Commande de lecture uniquement.
