Di-VentiX™
APPENDIX A / ANNEXE A
PAGE 137
COMMAND RESPONSE
COMMAND DESCRIPTION
VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX
DESCRIPTION
FRAME & LOGOS COMMANDS (continued) / COMMANDES DU MENU LOGOS & FRAME (suite)
lM lmod
Frame/logo
mode. Rd/Wr
0
3
0 = use & assignment mode.
1 = logo recording mode.
2 = frame recording mode.
3 = erasing mode.
lX
lsta
Status of the logo programmer
Rd
0 4
0 = free.
1 = logo/frame in recalling process.
2 = logo/frame in storing process.
3 = output format incompatible with the logo.
4 = logo/frame in erasing process.
lA
lpga
Logo 1 & frame assignment.
Rd/Wr
0
14
lB
lpgb
Logo 2 & frame assignment.
Rd/Wr
0
14
lC lcur
• In logo recording mode: Number of
the logo to be store (3 to 10).
• In frame recording mode: Number of
the frame to be store (1 or 2).
• In erase mode: number of the logo to
be erase (0 = erase all).
Rd/Wr
0 14
0 = no logo
1 = frame 1
2 = frame 2
3 = logo 1................... 10 = logo 8
11 = frame 3
12 = frame 4
13 = frame 5
14 = frame 6
lD
ldys
Display logo (according to PCH)
Rd/Wr
0
1
0 = Display OFF
1 = Display ON
lU
lhcp
Horiz. position of the logo storing area. Rd/Wr
0
255
lu
lvcp
Vert. position of the logo storing area. Rd/Wr
0
255
lW
lhsa
Horizontal size of the logo storing area. Rd/Wr
5
255 5 = 3%
255 = 100%
lS
lvsa
Vertical size of the logo storing area.
Rd/Wr
5
255 5 = 3%
255 = 100%
lH
lhpa
Horizontal position of the logo 1.
Rd/Wr
0
255
lh
lhpb
Horizontal position of the logo 2.
Rd/Wr
0
255
lV
lvpa
Vertical position of the logo 1.
Rd/Wr
0
255
lv
lvpb
Vertical position of the logo 2.
Rd/Wr
0
255
lP
lpxa
Pixels number in a line of the logo 1.
Rd
0 65535
lL
llna
Lines number in a logo 1.
Rd
0 65535
These 2 commands allow to calculate the
duration of the storing.
lp
lpxb
Pixels number in a line of the logo 2.
Rd
0 65535
ll
llnb
Lines number in a logo 2.
Rd
0 65535
These 2 commands allow to calculate the
duration of the storing.
lT
ltya
Logo 1 type.
Rd/Wr
0 1
lt
ltyb
Logo 2 type.
Rd/Wr
0 1
0 = frame
1= logo.
lO
lofa
Output format during the logo1 storing. Rd
0 11
lo
lofb
Output format during the logo2 storing. Rd
0 11
Identical as F command.
lR lsto
• In recording mode: frame/logo
storing.
• In erase mode: frame/logo erasing.
Rd
0
1
1 = STORE or ERASE (automatic reset).
lr
labt
Stop the frame storing.
Rd/Wr
0
1
1 = stop the frame storing (automatic reset).
PREVIEW / OUTPUT 2
lZ
LPTP
Logo transparency
Rd/Wr
0
15 0 = mini
15 = maxi
LE
LLEV
Luma key level.
Rd/Wr
0
255
lE LEMP
Status of the frame/logo memories.
(according to lcur)
Rd 0 1
0 = logo/frame memorized.
1 = empty memory.
Lb LBKC
Background
color.
Rd/Wr
0
7
Ld
LLD
Fade logo duration (0.01 second step). Rd/Wr 15
255 15 = 0.15 second
255 = 2.5 seconds
Lf
LFD
Fade frame duration (0.1 second step). Rd/Wr
5
50 5 = 0.1 second
50 = 5 seconds
LQ
LQTY
Frame quality
Rd/Wr
0
1
0 = native (4 frm)
1 = optimized (6 frm)
NOTE: To store a logo from the PREVIEW display you should:
Select the logo recording mode with the lM command (1lM).
Adjust the position and size of the logo storing area with the lU, lu, lH and lh commands.
Adjust the luma key level (with LE command) and the background color (with Lb command).
Select a logo memory with the lC command and do a store with lR command (1lR).
To store a frame from the PREVIEW display you should:
Select the frame recording mode with the lM command (2lM), and do a store with the lR command (1lR).
NOTE: To assign a logo/frame to an input on the PREVIEW display you should:
Select the assignment mode with the lM command (0lM).
Select the input with the PC command.
Select a stored logo/frame with lA, or lB commands.
Adjust the horizontal & vertical position of the logo with the lH, lh, lV & lv commands.
