APPENDIX A / ANNEXE A
Di-VentiX™
PAGE 140
COMMAND RESPONSE
COMMAND DESCRIPTION
VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX
DESCRIPTION
OTHERS COMMANDS / COMMANDES DIVERSES
N TBP
T-BAR
position.
Rd/Wr
0
255
ub
TBA
Executed percentage of the effect.
Rd
0 16383 0 = 0%
16383 = 100%
uv TBAV
T-BAR
availability.
Rd
0
1
0 = T-BAR unavailable. 1 = T-BAR available.
? DEV
Device
type.
Rd
0 65535 36 = DVX8022.
#
#1,....#0 Send all device parameters.
Rd
EMBEDDED SOFT-EDGE COMMANDS / COMMANDES DU MODE SOFT-EDGE INTÉGRÉ
eB
EDSB
Activate the embedded soft-edge mode Rd/Wr 0 1
0 = not activate
1 = activate
eS EDGS
Covering
size.
Rd/Wr
0 255
eC
PEDG
Extended input selection (works with
PC command).
Rd/Wr
0
1
0 = not extended
1 = extended.
eT EDGT
Softedge
type.
Rd/Wr
0 1
0 = horizontal
1 = vertical.
eV EDGV
Softedge
activation.
Rd/Wr
0 1
0 = inactive
1 = active.
LK
LUTC
LUT loading control.
Rd/Wr
0 10
1 = reset the LUT.
3 = LUT loading (softedge curve).
5 = linear softedge.
9 = softedge writing LUT selection.
10 = softedge displayed LUT selection.
K
L
-Values to set in the LUT (if LUTC=3)
-Softedge curve selection (if LUTC=9
or 10).
Rd/Wr
0 255
if LUTC = 3: 0 to 255.
if LUTC = 9 or 10: 0 or 1.
eJ
EDGR
Black level: red adjustment.
Rd/Wr
0 31
eK
EDGG
Black level: green adjustment.
Rd/Wr
0 31
eL
EDGB
Black level: bleu adjustment.
Rd/Wr
0 31
eH
EDGH
Black area: right adjustment
Rd/Wr
0 2047
Left area
el
EDGI
Black area: left adjustment
Rd/Wr
0 2047
eo
edgr
Black level: red adjustment.
Rd/Wr
0 31
ep
edgg
Black level: green adjustment.
Rd/Wr
0 31
eq
edgb
Black level: bleu adjustment.
Rd/Wr
0 31
em
edgh
Black area: right adjustment
Rd/Wr
0 2047
Right area
en
edgi
Black area: left adjustment
Rd/Wr
0 2047
ex
EDCH
Input number before the activation of a
PIP/double PIP effect.
Rd/Wr
0 8
0 = black
1 = input #1
2 = input #2................ 8 = input #8
NOTE:
(M) = MAIN output (sortie MAIN).
Rd/Wr = Read and write command / Commande de lecture et d'écriture.
(P) = PREVIEW output (sortie PREVIEW).
Rd = Read only command / Commande de lecture uniquement.
