Di-VentiX™ APPENDIX A / ANNEXE A
PAGE 141
COMMAND RESPONSE
COMMAND DESCRIPTION VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX DESCRIPTION
SOFT-EDGE BLENDING COMMANDS (CBD-UP option) / COMMANDES DE SOFT-EDGE BLENDING (option CBD-UP)
eS EDGS Covering size. Rd/Wr 0 255
eA EDGA Device position in the screen.
Rd/Wr 1 255
bits 0 to 3: device position.
bits 4 to 7: number of devices.
eP EFA Effect position in the screen.
Rd/Wr 0 255
bits 0 to 3: device position.
bits 4 to 7: number of devices.
eC PEDG Extended input selection (works with
PC command).
Rd/Wr 0 1 0 = not extended 1 = extended.
eT EDGT Softedge type. Rd/Wr 0 1 0 = horizontal 1 = vertical.
eV EDGV Softedge activation. Rd/Wr 0 1 0 = inactive 1 = active.
LK LUTC LUT loading control.
Rd/Wr 0 10
1 = reset the LUT.
3 = LUT loading (softedge curve).
5 = linear softedge.
9 = softedge writing LUT selection.
10 = softedge displayed LUT selection.
K L -Values to set in the LUT (if LUTC=3)
-Softedge curve selection (if LUTC=9
or 10).
Rd/Wr 0 255
if LUTC = 3: 0 to 255.
if LUTC = 9 or 10: 0 or 1.
eJ EDGR Black level: red adjustment. Rd/Wr 0 31
eK EDGG Black level: green adjustment. Rd/Wr 0 31
eL EDGB Black level: bleu adjustment. Rd/Wr 0 31
eH EDGH Black area: right adjustment Rd/Wr 0 2047
el EDGI Black area: left adjustment Rd/Wr 0 2047
AUDIO COMMANDS (OPT-iX-A option) / COMMANDES AUDIO (option OPT-iX-A)
RC ACH Audio source selection of the MAIN. Rd/Wr 1 8 1 = audio source #1.... 8 = audio source #8.
rc ach
Audio source selection of the PRELIST
output.
Rd/Wr 1 8 1 = audio source #1.... 8 = audio source #8.
RO AMOD Audio mode of the MAIN output. Rd/Wr 0 1 0 = auto follow 1 = breakaway
ro amod Audio mode of the PRELIST output. Rd/Wr 0 1 0 = auto follow 1 = breakaway
RV AVOL Mater volume of the MAIN output. Rd/Wr 0 255
rv avol Mater volume of the PRELIST output. Rd/Wr 0 255
RM AMUT Mute of the MAIN output. Rd/Wr 0 1 0 = mute OFF 1 = mute ON
rm amut Mute of the PRELIST output Rd/Wr 0 1 0 = mute OFF 1 = mute ON
RS AMNO Mono/stereo mode of the MAIN output. Rd/Wr 0 1 0 = stereo 1 = mono
rs amno Mono/stereo mode of the PRELIST. Rd/Wr 0 1 0 = stereo 1 = mono
RL ALVL Audio level (works with PC command) Rd/Wr 0 64 0 = minimum 1 = maximum
RB ABAL Audio balance (works with PC) Rd/Wr 0 64 0 = left to maximum 64 = right to maximum
RX AXMU Auxiliary source to MAIN. Rd/Wr 0 1 0 = used 1= unused.
rx axmu Auxiliary source to PRELIST. Rd/Wr 0 1 0 = used 1= unused.
NOTE: (M) = MAIN output (sortie MAIN). Rd/Wr = Read and write command / Commande de lecture et d'écriture.
(P) = PREVIEW output (sortie PREVIEW). Rd = Read only command / Commande de lecture uniquement.
