Di-VentiX™ APPENDIX A / ANNEXE A
PAGE 133
COMMAND RESPONSE
COMMAND DESCRIPTION VALUE /VALEUR
COMMANDE RÉPONSE DESCRIPTION DE LA COMMANDE
TYPE
MIN MAX DESCRIPTION
OUTPUT COMMANDS / COMMANDES DE SORTIE
FM OFTM Output formats selection (M). Rd/Wr 0 46
fp oftp Output formats selection (P). Rd/Wr 0 46
0 = 800x600 @50 1 = 800x600 @60
2 = 800x600 @72 3 = 800x600 @75
4 = 1024x768 @50 5 = 1024x768 @60
6 = 1024x768 @72 7 = 1024x768 @75
8 = 1280x768 @50 9 = 1280x768 @60
10 = 1280x768 @72 11 = 1280x768 @75
12 = 1400x1050 @50 13 = 1400x1050 @60
14 = 1400x1050 @72 15 = 1400x1050 @75
16 = 1365x1024 @75 17 = 1365x768 @75
18 = 848x480 @60
19 = 1280x720 @50
20 = 1280x720 @60 21 = 1365x1024 @50
22 = 1365x1024 @60 23 = 1365x1024 @72
24 = 1365x768 @50 25 = 1365x768 @60
26 = 1365x768 @72 27 = 848x480 @50
28 = 848x480 @72
29 = 848x480 @75
30 = 1280x768 @50 31 = 1280x768 @60
32 = 1280x768 @72 33 = 1280x768 @75
34 = 1600x1200 @50 35 = 1600x1200@60RB
36 = 1920x1080 @50 37 = 1920x1080 @59
38 = HDSDI 720p50 39 = HDSDI 720p59
40 = HDSDI 1080i50 41 = HDSDI 1080i59
42 = HDSDI 1080p24 43 = HDSDI 1080p25
44 = HDSDI 1080p29 45 = HDSDI 1080sf24
46 = HDSDI 1080sf25
FY OSYN Output sync selection (M). Rd/Wr 0 2
fy osyn Output sync selection (P). Rd/Wr 0 2
0 = H &V sync. 1 = Composite sync.
2 = SOG
FS SCRM Type of screen selection (M) Rd/Wr 0 1 0 = 4/3 screen 1 = 16/9 screen
fs scrp Type of screen selection (P) Rd/Wr 0 1 0 = 4/3 screen 1 = 16/9 screen
pm PAT Test pattern selection (M). Rd/Wr 0 7
pp pat Test pattern selection (P). Rd/Wr 0 7
0 = no pattern 1 = centering 2 = color
3 = grey scale 4 = grid.
5 = softedge
6 = multi-burst. 7 = H grey scale
XR REFR
Output rate selection (Mixer mode).
Output 1 rate selection (Matrix mode)
Rd/Wr 0 8
xr refr Output 2 rate selection (Matrix mode). Rd/Wr 0 8
0 = internal rate 1 = follow input #1
2 = follow input #2... 8 = follow input #8
NOTE: (M) = MAIN output (sortie MAIN). Rd/Wr = Read and write command / Commande de lecture et d'écriture.
(P) = PREVIEW output (sortie PREVIEW). Rd = Read only command / Commande de lecture uniquement.
