29 MAINTENANCE
ENGLISH Clean the Air Filter
Clean the air filters once every 2 weeks, or more, if
necessary.
NOTE
• The air filter can be broken when it is bent.
• When the air filter is not assembled correctly, dust
and other substances can enter into the indoor unit.
Type1
If you look at the indoor unit from above it, can
assemble the top filter easily.
1 Turn off the power to the unit.
2 Hold the knobs of the air filter, lift it up slightly.
3 Remove it from the indoor unit.
4 Clean the filter with a vacuum cleaner or with
lukewarm water with neutral detergent.
5 Dry the filter in the shade.
6 Insert the hooks of the air filter into the front
cover.
7
Push down hooks to assemble the air filter.
8 Check the side of the front cover for correct
assembly of the air filter.
Type2
1 Turn off the power to the unit.
2 Open the front cover.
• Lift up both sides of the cover slightly.
3 Hold the knobs of the air filters, pull them down
slightly and remove them from the indoor unit.
4 Clean the filters with a vacuum cleaner or with
lukewarm water with neutral detergent.
5 Dry the filters in the shade.
6 Insert the hooks of the air filters into the front
cover.
7 Check the side of the front cover for correct
assembly of the air filters.
