20 OPERATION
Using the Energy Saving
Function (Optional)
This function minimizes power consumption during
Cooling and increases the set temperature to the
optimal level for a more comfortable environment.
The temperature automatically settles at 22 °C if
desired temperature is below 22 °C The temperature
remains constant if it is above 22 °C
1 Turn the appliance on.
2 Press MODE button repeatedly to select the
Cooling Mode.
3 Press ENERGY SAVING button.
• is displayed on the display screen.
Using the Energy Control
Function (Optional)
1 Turn the appliance on.
2 Press ENERGY CTRL button.
• Press ENERGY CTRL button repeatedly to
select each step.
NOTE
• 1 step : The power Input is decreased by 20 %
compared to rated power input.
− is displayed on the display screen.
• 2 step : The power Input is decreased by 40 %
compared to rated power input.
− is displayed on the display screen.
• 3 step (Optional) : The power Input is decreased by
60 % compared to rated power input.
− is displayed on the display screen.
• (1 step), (2 step) is displayed on some indoor
units.
• This function is available with Cooling Mode.
• Capacity may decrease when Energy Control mode
is selected.
• Desired temperature is displayed about 5 seconds
if you press FAN SPEED , or button.
• Room temperature is displayed about 5 seconds if
you press ROOM TEMP button.
