19 OPERATION
ENGLISH Using the Energy Display
Function (Optional)
This function displays the amount of electricity
generated on the indoor display as the product
operates.
Display the Current Energy Usage
1 Turn the appliance on.
2
Press button and hold it about 3 seconds.
• The instantaneous power consumption ( or
kW
kWh ) is displayed for a while on some indoor
units.
Display the Cumulative Energy
Usage (Optional)
1 Turn the appliance on.
2
Press button and hold it about 3 seconds
twice.
• The cumulative power consumption ( kW
kWh ) is
displayed for a while on some indoor units.
NOTE
• It is not displayed on the wireless remote control.
• kW refers to instantaneous power consumption.
• kWh refers to cumulative power consumption.
• If it is more than 99 kWh, which is the range of
expression, maintain it as 99 kWh.
• Power off resets its value.
• Display wattage under 10 kW(h) with 0.1 kW(h)
unit, and display one over 10 kW(h) with 1 kW(h)
unit.
• The actual power may differ from the power
displayed.
Using the Light Off Function
(Optional)
Display Screen Brightness
You can set the brightness of the indoor unit display
screen.
• Press LIGHT OFF button.
NOTE
• Turn on/off the Display screen.
Using the Comfort Air
Function (Optional)
Comfort Vane Operation
This function conveniently sets the vane to a preset
position to deflect the supply air away from blowing
directly onto the occupants in the room.
1 Turn the appliance on.
2 Press COMFORT AIR button repeatedly and
select the desired direction.
• or is displayed on the display screen.
NOTE
• or is displayed on some indoor units.
• This function is disabled when you press MODE or
JET MODE button.
• This function is disabled and auto swing of vertical
direction is set up when you press
SWING
button.
• When this function is off, the horizontal vane
operates automatically depending on the set mode.
