5
CYCLE GUIDE - MANUAL CYCLES
TIMED DRY - It will run the dryer for the specified time on the control. Not all cycles and options are available on all models.
Items to dry: Cycle:
Drying
Temperature:
Available
Options: Cycle Details:
Any load
NOTE: Select Air
Only to dry foam,
rubber, plastic, or
heat-sensitive fabrics
Timed Dry High
Medium High
Medium
Low
Air Only
Wrinkle Prevent
Extra Power
Use to dry items to a damp level for items that do not require an
entire drying cycle. Select a drying temperature based on the type of
fabrics in your load. If you are unsure of the temperature to select for
a load, select the lower setting rather than the higher setting.
Small loads and
sportswear
Quick Dry High
Medium High
Medium
Low
Air Only
Wrinkle Prevent
Extra Power
For small loads of 3–4 items.
Medium load: Fill the dryer drum up to about 1/2 full.
Large load: Fill the dryer drum up to about 3/4 full.
Do not pack tightly. Items need to tumble freely.
Load Size Recommendations
For best results, follow the load size recommendations noted
for each cycle.
Small load: Fill the dryer drum with 3–4 items, not more
than 1/4 full.
CYCLE GUIDE - STEAM REFRESH CYCLES
(Steam models only)
Not all cycles and options are available on all models.
Items to
refresh: Cycle:
Drying
Temperature:
Available
Options: Cycle Details:
Shirts, blouses, and
slacks
Steam
Refresh
High
Medium High
Wrinkle Prevent
Extra Power
Use to reduce odors and light wrinkles. Do not add dryer sheets.
Models 7230 & 8230
NOTE:
These clothes dryer’s Government energy certifications were based on the Normal Cycle, Maximum Drying Temperature Setting,
Normal Dryness Level, Eco Strategy ON. The as - shipped defaults of Wrinkle Prevent off, Remote Enable off, Eco Strategy ON, were used.
Models 6230
NOTE:
These clothes dryer’s Government energy certifications were based on the Timed Dry Cycle, and Maximum Drying Temperature
Setting. The as - shipped defaults of Wrinkle Prevent off, Remote Enable off, Normal Dryness Level, Eco Strategy ON, were used.
DRYER ICONS
Image Description Status
Remote Enable
On
Off
Steam On
Reduce Static On
Reduce Static &
Steam
On
Image Description Status
Drum Light
On
Off
Smartgrid,
Peak rates in effect
On
Smart Delay
Smart Pause
