CONTROL PANEL AND FEATURES
5
6
4 2
3
1
Appearance may vary depending on model.
POWER
Touch to turn on/off or to stop/cancel a cycle.
CYCLE KNOB
Turn knob to select desired cycle.
EXTRA POWER
Press to boost drying power on any drying cycle by adding
extending time, heat, and tumbling.
1
3
4
2
DISPLAY LCD
Display LCD will show the cycle settings and estimated time
remaining. Adding or changing default options will also affect
time shown in display.
START/PAUSE
Touch and hold; cycle will start after countdown.
Touch START/PAUSE during a cycle to pause it. Touch again to
resume.
5 CYCLE MODIFIERS (Not all modifiers are available on all
cycles. See cycle guide for more information.)
NOTE: Dryer remembers the last completed cycle and cycle
settings. The next time you turn dryer on, it will be set to run the
last cycle.
TEMP
Touch to modify the cycle’s available temperatures. (Air Only,
Low, Medium, Medium High, High).
DRYNESS
Touch to modify the cycle’s available dry levels on the sensor
cycles (Less, Normal, More).
WRINKLE PREVENT
Touch to turn on/off and on with steam (select models). Wrinkle
Prevent adds up to 150 minutes of periodic tumbling and heat
to help reduce wrinkling. Wrinkle Prevent with Steam will add a
short steam cycle after 60 minutes to help smooth wrinkles.
CYCLE OPTIONS (Not all options are available on all cycles).
DRUM LIGHT
Touch to turn the drum light on/off.
REMOTE ENABLE
Touch each time you want to remotely control via the Maytag TM
app. Follow the instructions in the “GET THE MAYTAG TM APP
AND GET CONNECTED” section below for more details.
NOTE: Once Remote Enable has been selected, certain
interactions with the dryer will cause it to cancel Remote Enable.
Example: Opening the door.
6
STEAM OPTIONS
Touch to add Steam or Reduce Static to selected cycle. Steam
adds steam to the end of certain Sensor Cycle to help smooth
wrinkles. Reduce Static will automatically tumble, pause, and
introduce a small amount of moisture to the load to help reduce
static.
MORE TIME (Timed Dry & Quick Dry only)
Touch to increase the length of a Timed Dry or Quick Dry Cycle.
LESS TIME (Timed Dry & Quick Dry only)
Touch to decrease the length of a Timed Dry or Quick Dry Cycle.
CYCLE SIGNAL
Use this option to turn the signal indicating the end of a drying
cycle to Low, Medium, High, or Off.
NOTE: Press/hold CYCLE SIGNAL to select the volume.
DAMP DRY SIGNAL
Touch DAMP DRY SIGNAL or touch and hold CYCLE SIGNAL
(depending on the model) for at least 3 seconds to turn the
Damp Dry Signal on or off. User will get a sound and display
notification telling them “Items are damp. You can pause and
reposition for best results”.
CHECK VENT
The Check Vent alert is a feature available for Automatic cycles
only. This alert will show the status of airflow through the dryer
and the dryer vent system for the dryer’s life. During the sensing
phase at the beginning of the cycle if it detects a blocked vent
or low pressure it will display “Check vent. Clean lint screen or
vent for better performance.”
REMEMBER: The dryer will continue to operate even when
check vent notification is displayed, but poor airflow can impact
dry times and overall performance.
Display message can be cleared by pressing any key with the
exception of Power which will cancel the cycle.
