5. INSTALLING THE COOKING COMPONENTS
Parts Required:
4 x Cooking Grids (#2)
1 x Upper Cooking Rack (#1)
1 x Flame Broiler Diffuser (#4)
1 x Flame Broiler Slider (#3)
Installation:
NOTE: Both flame broiler parts are lightly coated with oil to avoid rusting when
shipped.
• Insert the flame broiler main plate into the grill barrel. Rest the flame broiler
main plate on the built-in ledge, right side first, of the main grill that directs
grease towards the grease tray. Slide the entire piece to the left side, and
the tray will lock into the raised tab above the burn grate. Note illustration
5A. The flame broiler main plate is used to distribute the heat evenly.
• Place the flame broiler slider on top of the flame broiler main plate, covering
the slotted openings. Ensure the raised tab is on the left, to easily adjust for
direct or indirect flame when cooking. Note illustration 5B.
NOTE: If the flame broiler main plate lays flat, on the base of the barrel, it is
installed incorrectly. The flame broiler should set at an angle, with the left
side sitting higher than the right.
• Place the cooking grids, side-by-side, on the grid ledge inside the main
barrel. Place the upper cooking rack on the upper ledge inside the main
barrel, locking into place, in the forward or receded position.
• The unit is now completely assembled.
IMPORTANT: To maintain the searing and grilling performance of your cooking
grids, regular care and maintenance is required. Wipe all stainless steel
surfaces – before use – to avoid any dirt, dust or oil from cooking into the metal
surface and causing discoloration during use.
6. CONNECTING TO A POWER SOURCE
• STANDARD OUTLET
This unit requires 110-120 volt, 60hz, 375w, service. It must be a 3-prong
grounded plug. Ensure grounded end is not broken off. The control uses a
110-120 volt, fast-blow fuse to protect the board from the igniter.
• GFCI OUTLETS
This unit works on most GFCI outlets, with a recommended size of 15 amp
service. If the GFCI outlet is highly sensitive to power surges, it will likely
trip during the start-up phase of operation. During the start-up phase, the
igniter draws 300-700 watts of electricity which can be too much power for
a GFCI outlet to handle. Each time the GFCI trips, it increases in sensitivity.
If the GFCI keeps tripping, replace the outlet or change to a non-GFCI outlet.
IMPORTANT: Do not attempt to rewire the appliance directly to a power
source unless there is a separate breaker switch near the appliance, clearly
marked for emergency shut-off. Turn power OFF when being serviced, or
when appliance is not in use.
