INSTRUMENTS, FEATURES AND CONTROLS
Side Covers
Your motorcycle is equipped with two removable side covers.
Remove the left side cover to access the battery. Remove the right
side cover to access the fuses and the rear brake fluid reservoir.
To remove either side cover, pull the rear corner of the side cover
out slightly until tab (A) is disengaged. Pull lower edge (B) out and
then front edge (C) to disengage remaining tabs and remove cover.
Be sure rubber grommets are in place before reversing the above
procedure to install the side covers. A solution of dish soap and
water can be used as a lubricant if required for installation.
Sidestand
The sidestand is located on the left side of the motorcycle.
Correctly retract the sidestand before operating the motorcycle. An improperly retracted sidestand
could come into contact with the ground and cause loss of control.
WARNING
To extend the sidestand, swing it out from the end until it is fully extended. Lean the motorcycle toward the
sidestand until the sidestand firmly supports the motorcycle.
To retract the sidestand, lean the motorcycle away from the sidestand until the motorcycle is fully upright. Swing
the sidestand back into its fully retracted position.
A
B
C
