129
MAINTENANCE
Headlamp Adjustment
The headlamp high beam should shine straight ahead
of the motorcycle. The top of headlamp high beam
should be just below the center of the lamp at a
distance of 25 feet (7.62 m). The low beam pattern
spreads farther right of center than the high beam
(U.S. & Canada).
1. Check and adjust the tire pressure (page 118)
2. Adjust ride height to specification (page 97)
before adjusting headlight.
3. Straddle the motorcycle in an upright position
and sit in the operator’s seat.
4. Set the ignition switch to the ON position and
set the headlamp to High beam. Check the
headlamp for correct aim.
5. To adjust the headlamp vertically, loosen pivot
nut (1) while holding bolt (2). Aim headlight
and hold in position while tightening nut.
Torque: 35 ft-lbs (47.5 Nm)
6. To adjust the lamp horizontally, loosen the nut
(3), aim headlight and hold in position while
tightening nut.
Torque: 28 ft-lbs (38 Nm)
7. Verify proper headlamp adjustment and
re-adjust if necessary.
25 feet (7.62 m)
Center of Headlamp
High Beam
3 1
2
(VEGAS EIGHT BALL Shown)
