15
SAFETY
LOADING EXAMPLES -- KINGPIN & KINGPIN TOUR
EXAMPLE 3: Item Weight
KINGPIN KINGPIN- with full capacity of all fluids 685 lbs (311 kg) KINGPIN
with no accessories or cargo. Operator - with recommended riding apparel 230 lbs (104 kg)
Gross Vehicle Weight Rating:
1210 lbs (549 kg) Passenger - with recommended riding apparel 165 lbs (75 kg)
1210 lbs (549 kg)
Total Weight 1080 lbs (490 kg)
Item Weight
EXAMPLE 4: KINGPIN - with full capacity of all fluids 685 lbs (311 kg)
KINGPIN
i h ddl b d
Weight of saddlebags (hard bags & brackets) 33 lbs (15 kg)
with saddlebags and cargo.
Cargo - saddlebags at capacity 14 lbs (6 kg)
Gross Vehicle Weight Rating:
1210 lbs (549 kg)
Operator - with recommended riding apparel 230 lbs (104 kg)
1210 lbs (549 kg)
Passenger - with recommended riding apparel 165 lbs (75 kg)
Total Weight 1127 lbs (511 kg)
Item Weight
EXAMPLE 5: KINGPIN TOUR- with full capacity of all fluids 764 lbs (347 kg)
KINGPIN TOUR
i h
Cargo - top box at capacity 20 lbs (9 kg)
with cargo.
Cargo - saddlebags at capacity 14 lbs (6 kg)
Gross Vehicle Weight Rating:
1210 lbs (549 kg)
Operator - with recommended riding apparel 230 lbs (104 kg)
1210 lbs (549 kg)
Passenger - with recommended riding apparel 165 lbs (75 kg)
Total Weight 1193 lbs (541 kg)
NOTE: As shown in Example 4, the weight of any accessory items such as saddlebags and brackets or individual items in addition to
the cargo, must be added to the base weight of the motorcycle. NEVER exceed GVWR. If you have any questions regarding safe
loading of your VICTORY motorcycle, please consult an authorized VICTORY dealer.
