32
COMPONENT IDENTIFICATION
RIGHT SIDE -- VEGAS / VEGAS EIGHT BALL
1. Drive Belt (under guard)
2. Passenger Seat (except VEGAS EIGHT BALL)
3. Seat Strap
4. Operator’s Seat
5. Side Cover
6. Rear Shock Absorber (access through RH side cover)
7. Front Turn Signal
8. Front Fork
9. Oil Cooler
10. Rear Brake Pedal
11. Operator Foot Rest
12. Engine Oil Fill Cap/Dipstick
13. Rear Brake Fluid Reservoir (under side cover)
14. Drive Sprocket (under cover)
15. Fuses (under side cover)
16. Passenger Foot Rest (except VEGAS EIGHT BALL)
17. Exhaust Muffler (2)
1 2 4 5 6
7
8
9
10 11 12
13 14 15 16
3
17
