107
MAINTENANCE
Clutch
Lubricate Clutch Lever
1. Remove right side cover.
2. Loosen the cable adjuster lock nut (see page 108.)
3. Turn the cable adjuster all the way in to provide maximum lever free
play.
4. Remove clutch lever pivot nut (1) and pivot screw (2).
5. Disconnect the clutch cable from the clutch lever.
6. Remove any old grease and dirt from the clutch lever, bushing, and
lever housing.
7. Lubricate the clutch lever, bushing and lever pivot screw with
VICTORY Moly Assembly Grease (P/N 2871460).
8. Reconnect the clutch cable and reinstall the lever and lever pivot screw.
9. Install nut.
10. Hold pivot screw down and torque nut to 52 in-lbs (6 Nm)
11. Adjust clutch freeplay (page108)
1
2
MOS 2
