3
DETAILED PLANNING DIMENSIONS
Product Dimensions
in
mm
H
Strain Relief from Side (electric)
15
3
∕
4
400
I
Exhaust Duct from Side
14
7
∕
16
366
J
Power Cord from Side (gas)
14
3
∕
4
375
K
Gas Connection from Side
9
3
∕
16
234
L
Water Inlet from Side
4
101
Power Cord Length (Canadian)
52
3
∕
8
1330
Gas Power Cord Length
60
1524
M
Strain Relief Height (electric) (with leveling legs not extended)
28
1
∕
8
714
N
Power Cord Height (Gas) (with leveling legs not extended)
32
3
∕
8
822
O
Gas Connection Height (with leveling legs not extended)
1
11
∕
16
43
P
Exhaust Duct Height (with leveling legs not extended)
5
1
∕
8
130
Q
Water Inlet Height (with leveling legs not extended)
30
1
∕
2
774
R
Strain Relief Height (Electric) (with leveling legs fully
extended)
29
3
∕
4
755
S
Exhaust Duct Height (with leveling legs fully extended)
6
11
∕
16
170
T
Power Cord Height (Gas) (with leveling legs fully extended)
34
863
U
Gas Connection Height (with leveling legs fully extended)
3
5
∕
16
84
V
Water Inlet Height (with leveling legs fully extended)
32
1
∕
8
816
Electric
Gas
H
M Q
L
I
P
R
V
S
J
N
K
O
T
U
