15
REVERSING DOOR
1 Open the door and begin removing the four screws that
attach the hinge to the front panel door opening. Start
by only removing one screw per hinge. Then only loosen
the two remaining screws while fi rmly holding the door to
prevent damage to hinge, front panel or door. After the
remaining screws are loosened, continue to remove all.
2 Place door on a towel (front side down) to prevent
scratches to paint. Remove all screws on all edges of door.
1 Be sure you have adequate swing area before
reversing door.
2 You will need a screw driver with a Phillips bit.
3 Protect fl at work surface, such as top of dryer or fl oor
near dryer, with a soft cloth or towel.
4 Be sure dryer is unplugged from power source!
Tools needed:
Your dryer is designed so the door swing may be reversed at any time without additional parts. Conversion is accomplished by
transferring hinges and door strike to the opposite sides of the cabinet.
Screwdriver with
Phillips bit
FRONT PANEL
HINGE SCREWS (x 4)
WARNING
ELECTRICAL SHOCK HAZARD
Failure to disconnect power source before
servicing could result in personal injury or
even death.
3 Separate inner door from outer door and rotate outer door
180 degrees.
4 Reinsert inner door to outer door and re-install hinges and
all screws removed earlier.
