DETAILED PLANNING DIMENSIONS
Product Dimensions
in
mm
H
Strain Relief from Side (Electric)
15
3
∕
4
400
I
Exhaust Duct from Side
14
7
∕
16
366
J
Power Cord from Side (Gas)
14
3
∕
4
375
K
Gas Connection from Side
9
3
∕
16
234
Power Cord Length (Canadian)
52
3
∕
8
1330
Gas Power Cord Length
60
1524
L
Strain Relief Height (Electric) (with leveling legs not extended)
28
1
∕
8
714
M
Power Cord Height (Gas) (with leveling legs not extended)
32
3
∕
8
822
N
Gas Connection Height (with leveling legs not extended)
1
11
∕
16
43
O
Exhaust Duct Height (with leveling legs not extended)
5
1
∕
8
130
P
Strain Relief Height (Electric) (with leveling legs fully extended)
29
3
∕
4
755
Q
Exhaust Duct Height (with leveling legs fully extended)
6
11
∕
16
170
R
Power Cord Height (Gas) (with leveling legs fully extended)
34
863
S
Gas Connection Height (with leveling legs fully extended)
3
5
∕
16
84
3
Electric
Gas
H
L
I
O
P
R
S
Q
J
M
K
N
