English 3
Clearances and Dimensions
• For safety considerations do not install drawer in any
combustible cabinetry which is not in accord with the
stated clearances and dimensions in the "MicroDrawer
®
Microwave Oven Measurements" section following.
See Figure 3 (standard installation) or Figure 4 (flush
installation).
• Dimensions that are shown in Figure 3 (standard
installation) or Figure 4 (flush installation) must be used.
Given dimensions provide minimum clearance. Locate
electrical outlet in the shaded area in the upper left-hand
corner of the cutout. See Figure 6.
• Supporting surface must be solid and level. Pay special
attention to the floor of the cabinet opening on which
the MicroDrawer
® microwave oven will sit. The floor of
the opening should be constructed of plywood strong
enough to support the weight of the oven (approxi-
mately 100 pounds).
• Check the location where the MicroDrawer ® microwave
oven will be installed for proper electrical supply.
• Your oven can be built into a cabinet or wall as a stand-
alone unit or under a built-in gas or electric wall oven
and the followings:
INDUCTION
COOKTOPS
ELECTRIC
COOKTOPS
GAS
COOKTOPS
RANGETOPS
CIT304TB
CIT304TM
CIT30XWBB
CIT365TB
CIT367TGS
CIT367TG
CIT367TM
CIT367TMS
CIT36XWBB
CIT36XWB CEM305TB
CET305TB
CEM366TB
CET366TB SGS305TS
SGSP305TS
SGSX305TS
SGSXP305TS
SGS365TS
SGSP365TS
SGSX365TS
SGSXP365TS PCG305W
PCG364WD
PCG364WL
PCG366W
• Check to be sure that there is a clearance of 2 inches or
greater between the top of the MicroDrawer ® microwave
oven unit and the bottom of a built-in wall oven above it.
• The microwave interior will accommodate a 9" x 13"
oblong dish or a bag of microwave popcorn.
Safety Codes and Standards
This appliance complies with the latest version of one or
more of the following standards:
• CAN/CSA C22.2 No. 61 - Household Cooking Ranges
• UL 858 - Household Electric Ranges
• CAN/CSA C22.2 No. 150 - Microwave Ovens
• UL 923 - Microwave Cooking Appliances
• UL 507 - Electric Fans
• CAN/CSA C22.2 No. 113 - Fans and Ventilators
• CSA C22.2 No. 64 - Household Cooking and Liquid-
Heating Appliances
• UL 1026 - Electric Household Cooking and Food Serving
Appliances
It is the responsibility of the owner and the installer to
determine if additional requirements and/or standards apply
to specific installations.
Grounding Instructions
This appliance must be grounded. In the event of an electri-
cal short circuit, grounding reduces the risk of electric shock
by providing an escape wire for the electric current. This
appliance is equipped with a cord having a grounding wire
with grounding plug. The plug must be plugged into a outlet
that is properly installed and grounded.
WARNING
Improper grounding can result in a risk of electric
shock.
Consult a qualified electrician if the grounding instructions
are not completely understood, or if doubt exists as to
whether the appliance is properly grounded.
Do not use an extension cord. If the power supply cord is too
short, have a qualified electrician install an outlet near the
appliance.
The installer must perform a ground continuity check on
the power outlet box before beginning the installation to
insure that the outlet box is properly grounded. If not prop-
erly grounded, or if the outlet box does not meet Electrical
Requirements, a qualified electrician should be employed to
correct any deficiences.
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
