1 installation mécanique – Yaskawa AC Drive P1000 Industrial Manuel d'utilisation
Page 40
Table 2.6 Dimensions du boîtier IP00/à châssis ouvert, classe de 200 V
Modèle
de
variateur
de vitesse
Figure
Dimensions mm (in)
Poids
kg (lb)
L
H
P
L1
L2
H1
H2
P1
É1
É2
d
2A0250A
<1>
1
450
(17.72)
705
(27.76)
330
(12.99)
325
(12.80)
10
(0.39)
680
(26.77)
12
(0.49)
130
(5.12)
3.3
(0.13)
3.3
(0.13)
M10
76
(167.6)
2A0312A
<1>
450
(17.72)
705
(27.76)
330
(12.99)
325
(12.80)
10
(0.39)
680
(26.77)
12
(0.49)
130
(5.12)
3.3
(0.13)
3.3
(0.13)
M10
80
(176.4)
2A0360A
<1>
500
(19.69)
800
(31.50)
350
(13.78)
370
(14.57)
10
(0.39)
773
(30.43)
13
(0.51)
130
(5.12)
4.6
(0.18)
4.6
(0.18)
M12
98
(216.1)
2A0415A
500
(19.69)
800
(31.50)
350
(13.78)
370
(14.57)
10
(0.39)
773
(30.43)
13
(0.51)
130
(5.12)
4.6
(0.18)
4.6
(0.18)
M12
99
(218.3)
<1> Les clients peuvent convertir ces modèles aux boîtiers IP20/NEMA type 1 au moyen d'une trousse IP20/NEMA type 1.
Table 2.7 Dimensions du boîtier IP00/à châssis ouvert, classe de 400 V
Modèle
de
variateur
de
vitesse
Figure
Dimensions mm (in)
Poids
kg (lb)
L
H
P
L1
L2
L3
L4
H1
H2
P1
É1
É2
d
4A0208A
<1>
1
450
(17.72)
705
(27.76)
330
(12.99)
325
(12.80)
10
(0.39)
–
–
680
(26.77)
12.4
(0.49)
130
(5.12)
3.3
(0.13)
3.3
(0.13)
M10
79
(174.2)
4A0250A
<1>
500
(19.69)
800
(31.50)
350
(13.78)
370
(14.57)
10
(0.39)
–
–
773
(30.43)
13
(0.51)
130
(5.12)
4.6
(0.18)
4.6
(0.18)
M12
96
(211.6)
4A0296A
<1>
500
(19.69)
800
(31.50)
350
(13.78)
370
(14.57)
10
(0.39)
–
–
773
(30.43)
13
(0.51)
130
(5.12)
4.6
(0.18)
4.6
(0.18)
M12
102
(224.9)
4A0362A
<1>
500
(19.69)
800
(31.50)
350
(13.78)
370
(14.57)
10
(0.39)
–
–
773
(30.43)
13
(0.51)
130
(5.12)
4.6
(0.18)
4.6
(0.18)
M12
107
(235.9)
4A0414A
2
500
(19.69)
950
(37.40)
370
(14.57)
370
(14.57)
7.9
(0.31)
–
–
923
(36.34)
13
(0.51)
135
(5.31)
4.6
(0.18)
4.6
(0.18)
M12
125
(275.6)
4A0515A
3
670
(26.38)
1140
(44.88)
370
(14.57)
440
(17.32)
6
(0.24)
220
(8.66)
–
1110
(43.70)
15
(0.59)
150
(5.91)
4.6
(0.18)
4.6
(0.18)
M12
216
(476.2)
4A0675A
670
(26.38)
1140
(44.88)
370
(14.57)
440
(17.32)
6
(0.24)
220
(8.66)
–
1110
(43.70)
15
(0.59)
150
(5.91)
4.6
(0.18)
4.6
(0.18)
M12
221
(487.2)
4A0930A
4
1250
(49.21)
1380
(54.33)
370
(14.57)
1110
(43.70)
6
(0.24)
330
(13.00)
440
(17.32)
1345
(52.95)
15
(0.59)
150
(5.91)
4.6
(0.18)
4.6
(0.18)
M12
545
(1201.5)
4A1200A
4
1250
(49.21)
1380
(54.33)
370
(14.57)
1110
(43.70)
6
(0.24)
330
(13.00)
440
(17.32)
1345
(52.95)
15
(0.59)
150
(5.91)
4.6
(0.18)
4.6
(0.18)
M12
555
(1223.6)
<1> Les clients peuvent convertir ces modèles aux boîtiers IP20/NEMA type 1 au moyen d'une trousse IP20/NEMA type 1.
Table 2.8 Dimensions du boîtier IP00/à châssis ouvert, classe de 600 V
Modèle
de
variateur
de vitesse
Figure
Dimensions mm (in)
Poids
kg (lb)
L
H
P
L1
L2
L3
L4
H1
H2
P1
É1
É2
d
5A0125A
<1>
1
450
(17.72)
705
(27.76)
330
(12.99)
325
(12.80)
10
(0.39)
–
–
680
(26.77)
12.4
(0.49)
130
(5.12)
3.3
(0.13)
3.3
(0.13)
M10
79
(174.2)
5A0145A
<1>
450
(17.72)
705
(27.76)
330
(12.99)
325
(12.80)
10
(0.39)
–
–
680
(26.77)
12.4
(0.49)
130
(5.12)
3.3
(0.13)
3.3
(0.13)
M10
79
(174.2)
5A0192A
<1>
500
(19.69)
800
(31.50)
350
(13.78)
370
(14.57)
10
(0.39)
–
–
773
(30.43)
13
(0.51)
130
(5.12)
4.6
(0.18)
4.6
(0.18)
M12
107
(235.9)
5A0242A
<1>
500
(19.69)
800
(31.50)
350
(13.78)
370
(14.57)
10
(0.39)
–
–
773
(30.43)
13
(0.51)
130
(5.12)
4.6
(0.18)
4.6
(0.18)
M12
107
(235.9)
<1> Les clients peuvent convertir ces modèles aux boîtiers IP20/NEMA type 1 au moyen d'une trousse IP20/NEMA type 1.
2.1 Installation mécanique
40
YASKAWA TOFP YAIP1U 01B Variateur de vitesse ca YASKAWA - P1000 Manuel de mise en route rapide
