33
COMPONENT IDENTIFICATION
LEFT SIDE VIEW -- VEGAS / VEGAS EIGHT BALL
1. Front Fork
2. Front Turn Signal
3. Headlamp
4. Air Filter
5. Spark Plug (2)
6. Ignition Switch
7. Left Side Cover
8. Battery (under side cover)
9. Rear Turn Signal
10. Taillight
11. Rear Brake Caliper
12. Rear Axle Adjuster (1 each side)
13. Horn
14. Passenger’s Foot Rest
(except VEGAS EIGHT BALL)
15. Oil Filter
16. Sidestand
17. Evaporative Canister - California Models
(lower left by swingarm)
18. Operator’s Foot Rest
19. Gear Shift Lever
20. Front Brake Caliper
1
2
3
4
5
6
7 8
9
10
11
12 14 15 16 17
18 19
20
13
