159
SPECIFICATIONS
Model Year 2006 VEGAS / VEGAS EIGHT BALL KINGPIN
Engine Freedomt V-Twin Freedomt V-Twin
Engine Model Number (Black--1202889) (Silver--1202890)
(8-Ball--1202891)
(Black -- 1202889) (Silver -- 1202890)
Configuration Freedomt 100/6 50_ V-Twin 4 Stroke Freedomt 100/6 50_ V-Twin 4 Stroke
Displacement 100 cu in (1634 cc) 100 cu in (1634 cc)
Cooling System Air & Oil Air & Oil
Compression Ratio 9.8:1 9.8:1
Valve Train 4 Valves Per Cylinder
With Hydraulic Lifters & Cam Chain Adjusters
4 Valves Per Cylinder
With Hydraulic Lifters & Cam Chain Adjusters
Bore and Stroke 101 x 102 mm 101 x 102 mm
Throttle Body Bore 44 mm 44 mm
Exhaust System Dual-Staggered Dual-Staggered
Lubrication System Wet Sump Wet Sump
Spark Plug / Gap NGK CPR6EB-9 .032 in (0.8 mm) NGK CPR6EB-9 .032 in (0.8 mm)
Chassis
Front Suspension Type/Travel Telescopic Fork / 5.1 in (13 cm) Inverted Telescopic Fork / 5.1 in (13 cm)
Rear Suspension Type/Travel Single, Monotube Gas,
Preload Adjustable / 3.9 in (10 cm)
Single, Monotube Gas,
Preload Adjustable / 3.9 in (10 cm)
Swingarm Forged and Cast Aluminum
With Rising Rate Linkage
Forged and Cast Aluminum
With Rising Rate Linkage
Front Brakes Single 300 x 5 mm Floating Rotor
4 Piston Caliper
Single 300 x 5 mm Floating Rotor
4 Piston Caliper
Rear Brakes Single 300 x 5 mm Floating Rotor
2 Piston Caliper
Single 300 x 5 mm Floating Rotor
2 Piston Caliper
