127
MAINTENANCE
Seat Removal and Installation
There are two separate seats, the operator’s seat and the passenger seat (except 8-Ball). It is not necessary to
remove the passenger seat for regular maintenance. The passenger seat mounting screws are located on each side of
the seat under the chrome covers.
Always make sure the seats are securely fastened before riding the motorcycle. A loose seat could
cause a sudden shift in riding position, causing loss of control.
WARNING
1. Remove the right and left side covers.
2. Remove the fuse box from the bracket (see page 27).
3. Remove the screws located on the right and left sides of
the operator’s seat.
4. Lift the rear of the seat and pull rearward and up to
remove.
5. To reinstall the seat, slide the tongue of the seat into the
rubber mount at rear of fuel tank.
6. Push down on the rear of the seat until the screw holes
align.
7. Ensure the front seat mount is engaged in the front
rubber mount, then install the screws and tighten securely.
8. Reinstall the fuse box and the left and right side covers.
1. Remove Side Covers
2. Remove Fuse Box and
Right Seat Screw
3. Remove Left Seat Screw
4. Lift Rear of Seat, Pull
Rearward
2
3
4
