STUDIO SCAN XTD825 / 625™
PAGE 9
Chapter 4 : LCD SCREEN DESCRIPTION
4-1. INTRODUCTION
The LCD screen is composed of 2 modes: the STATUS MODE and the CONTROL MODE.
• The STATUS MODE indicates the input and output status of the STUDIO SCAN XTD825 / 625 ™ .
• The CONTROL MODE allows to select and adjust the parameters of the STUDIO SCAN XTD825 / 625 ™ .
4-2. LCD CONTROL BUTTONS
The LCD screen is controlled by 2 buttons and 1 knob:
 knob: To scroll thru the different menus.
EXIT / MENU button: • From the STATUS MODE, press this button to display the CONTROL MODE.
• From the CONTROL MODE, press this button to:
- return to the previous menu without safeguarding the selection.
- return to the STATUS MODE (press several times).
ENTER button: • From the STATUS MODE, press this button to return to the last consulted menu.
• From the CONTROL MODE, press this button to confirm a selected item.
NOTE: When entering in the CONTROL MODE, the LCD window will automatically display the STATUS MODE
after 60 seconds of inactivity of the front panel buttons.
4-3. STATUS MODE
When switching ON, the LCD SCREEN shows the product's name and reference as follows:
c STUDIO SCAN XTD825 STATUS MENU
d Version _._
output NTSC f STATUS MENU
e internal 59.94 Hz g
input SVGA h STATUS MENU
i H = 60.1 K V = 75 Hz j
c Device designation.
d Device version.
e Synchronization mode.
f Output standard.
g Output frame rate.
h Input format.
i Horizontal input frequency.
j Vertical input frequency.
