Chapter 5 : LCD FUNCTIONS DESCRIPTION
1
[INPUT MENU] + ENTER.
1-1
[input status] + ENTER.
Displays the input status.
• [INPUT]:
[XGA] = input format.
[60 Hz] = input frame frequency.
• [GENLOCK]: [none] = genlock signal not detected.
1-2
[Input type] + ENTER. (Available on XTD825 version with optional DVI input)
Select one of the following input type with + ENTER:
• [analog] = Analog computer source connected to the HD15 input connector.
• [DVI] =
Digital computer source connected to the DVI input connector.
1-3
[Genlock H. ph.] + ENTER.
This function allows to adjust the genlock horizontal phase. Adjust with + ENTER.
1-4
[Genlock Sc. ph.] + ENTER.
This function allows to adjust the genlock Subcarrier phase. Adjust with + ENTER.
1-5
[SOG input] + ENTER.
Select [Yes] if your input signal is in RGsB (SOG), and valid with ENTER.
1-6
[H sync load] + ENTER.
Select the Horizontal sync load of your input signal with + ENTER.
1-7
[Genlock load] + ENTER.
Set on Hi-Z if the genlock out is used.
2
[OUTPUT MENU] + ENTER.
2-1
[output status] + ENTER.
Displays the output status.
2-2
[output std.] + ENTER.
Select one of the following standard with + ENTER:
• [NTSC] = NTSC standard for composite and S.VIDEO output and 60Hz frame rate for RGB/S and YUV
output.
• [PAL] = PAL standard for composite and S.VIDEO output and 50Hz frame rate for RGB/S and YUV
output.
• [NTSCj] = NTSC japan standard for composite and S.VIDEO output and 60Hz frame rate for RGB/S and
YUV output.
2-3
[output rate] + ENTER.
Select one of the following functions with + ENTER.
• [internal] = The output standard depends of the selected output standard in LCD menu # 2-2.
• [genlock] = The output standard is synchronized onto the genlock input standard.
2-4
[RGB/YUV out] + ENTER.
Select the RGB/YUV wanted output with + ENTER.
• [YUV] = component video output.
• [RGBS] = RGB/S video output.
• [RGsB] = RGB with Sync On Green video output.
2-5
[test pattern] + ENTER.
Select one item with + ENTER.
• [yes] = displays a test pattern onto the output.
• [no] = turns OFF the test pattern.
