DESCRIPTION SYMBOL ID OBJECTS OBJECT NAME UNITS
Puissance apparente L3 Aparent power L3 kVA AI42 AppPwrPh3 kVA
Puissance apparente
triphasée
Three phase aparent
power
kVAIII AI43 AppPw3Ph kVA
Demande maximale l1 Maximum demand I1 Md (A1) AI44 MaxDemand_A1 A
Demande maximale l2 Maximum demand I2 Md(A2) AI45 MaxDemand_A2 A
Demande maximale l3 Maximum demand I3 Md(A3) AI46 MaxDemand_A3 A
Demande maximale A Maximum demand A A III AI47 MaxDemand_A A
Demande maximale kW Maximum demand kW kW III AI48 MaxDemand_kW kW
Demande maximale
kVA
Maximum demand kVA kVA III AI49
MaxDemand_
kVA
kVA
Analog Value Object Type
1. Dynamically creatable using BACnet’s CreateObject service? No
2. Dynamically deleatable using BACnet’s DeleteObject service? No
3. List of optional properties supported:
4. List of all properties that are writable where not otherwise required by this standard
5. List of propietary properties:
Property Identifier
Property Datatype Meaning
5. List of object identifiers and their meaning in this device
Object ID
Object Name Description
AV1 MAC_Address MAC
AV2 BaudRate BAUD RATE
AV3 Device_ID DEVICE ID
Device Object Type
1. Dynamically creatable using BACnet’s CreateObject service? No
2. Dynamically deleatable using BACnet’s DeleteObject service? No
3. List of optional properties supported:
Description, Protocolo_Conformance_Class
4. List of all properties that are writable where not otherwise required by this standard
Object_Name
Max_Master
Max_Info_Frames
Object_Identifier
5. List of propietary properties:
5. List of any property value range restrictions
Property Identifier
Restrictions
Object_Name < 7 bytes
Object_Identifier Device Type only
Number_Of_APDU_Retries 0-255
APDU_Timeout 0-65535 miliseconds
Vendor_Identifier 0-65535
Data Link Layer Options (check all that supported):
X MS/TP master (Clause 9), baud rate(s): 9.6, 19.2kB/s
Character Sets Supported (check all that apply):
Indicating support for multiple character set does not imply that they can all be supported simulta-
neously.
X ANSI X3.4
