7
Functions
EXTENDIBLE ZONE (DOUBLE ZONE)
Depending on the diameter of the container, the zone adapts itself
automatically, turning on partially (inner zone) or completely (outer
zone). For more information, refer to the minimum diameter table.
IMPORTANT: Place the pot making sure that its center
corresponds to the center of the cooking zone in use.
Auto
The “Auto” button activates the auto cooking functions. Place
the pot in position and turn on the cooking zone. Then press the
"Auto” button. “A” will appear on the display. The indicator for the
first auto cooking feature available for the cooking will light up.
Select the desired auto cooking function by pressing the
“Auto” one or more times. If no button is pressed the function is
activated automatically after 3 seconds. The power level is not
editable. The cooktop sets a default power level.
To deactivate the special functions, press ON/OFF button or press
“Auto” button until you see a dash “-” is visible on the display.
MELT
This function allows you to bring food to the ideal temperature for
melting and to maintain the condition of the food. This method
does not damage delicate foods such as chocolate, and helps
prevent food sticking to the pot/pan.
SIMMER
This function is ideal for maintaining a simmering temperature,
allowing you to cook food for long periods. Ideal for long-cooking
recipes (rice, sauces, soups) with liquid bases.
A. Single size
B. Dual size
Auto
Auto
Auto
Daily Use
POSITIONING
Do not cover the control panel symbols with the cooking pot.
NOTE: In the cooking zones close to the control panel, it is
advisable to keep pots and pans inside the markings (taking both
the bottom of the pan and the upper edge into consideration, as
this tends to be larger).
This prevents excessive overheating of the keypad. When grilling
or frying, use the rear cooking zones.
NOTE: Do not set any items on the control panel at any time.
To Use:
Press “ON/OFF” for at least one second to turn on the desired
cooking zone. A dash (“-”) will be shown on display. Press the “+”
or “−” button of the required cooking zone to adjust the power. At
first the level “5” will be shown in line with the area.
The Boost function is reached by pressing the power level button
until the letter “P” is shown in the digit display. The boost can be
activated on all zones.
To deactivate the cooking zones:
Select the “ON/OFF” button of the cooking zone desired.
CONTROL PANEL LOCK
To lock the settings and prevent it from being switched on
unintentionally, press and hold the “Key Lock” button for
3 seconds. A beep and an indicator light above the symbol
indicates that this function has been activated. The control panel is
locked except “ON/OFF” of each cooking zone.
To unlock the controls, repeat the activation procedure.
TIMER
The cooktop has a Timer. The Timer can be set in minutes up to
99 minutes.
To Use Timer:
1.
Press “+” button to select the desired time.
NOTE: Press and hold the “+ or -” buttons for a few seconds
to quickly scroll through the time.
2. After releasing the button, the timer countdown will start in
3 seconds.
3. If needed to adjust the time, press “+” button to increase the
time or “-” button to decrease the time.
4. When countdown is over, timer tone will sound. The display
will indicate “00” and chime will play some times.
Then the display will turn off.
To Cancel:
Press “-” button until display shows “00” or press simultaneously
“-” and “+”.
WARNING
Fire Hazard
Turn off all controls when done cooking.
Failure to do so can result in death or fire.
