Monogram 36 Inch Freestanding Professional Induction Smart Range Owner's Manual - Manuel (Page 14)

14
49-2001169 Rev. 1
KITCHEN TIMER
To Turn On
Touch the Timer pad. Touch the + or - arrows to choose
the desired number of minutes. Timer automatically starts
10 seconds after pad is touched, or if the Timer pad is
touched.
To Turn Off
Press and release the Timer pad to cancel timer. Alarm will
sound continuously when time is up until user turns timer
off.
NOTE: Use the kitchen timer to measure cooking time
or as a reminder. The kitchen timer does not control the
cooking elements.
COOKTOP LOCKOUT
Lock
If the square indicator light is off, touch the LOCK
COOKTOP pad for 3 seconds. The square indicator light
should then turn on.
Unlock
If the square indicator light is on, touch the LOCK
COOKTOP pad for 3 seconds. The square indicator light
should then turn off.
See Cooktop Custom Settings section to activate Auto
Lock feature.
POWER SHARING
A 30" cooktop has 2 cooking zones, and a 36" cooktop
has 3 cooking zones. If two elements in the same zone
are in use and at least one element is at the maximum
power level (Hi), the Hi setting will operate at a reduced power level. Note that the display will not change. This is
how power is shared between two elements in the same
cooking zone.
USING THE RANGE
30” cooktop. 36” cooktop.
Left Zone Right Zone Center Zone Left Zone Right Zone
Control Lock
Indicator
