Specifications
AC Line Voltage: UL Rating - Single phase 120V, 60Hz, AC only
CSA Rating - Single phase 117V, 60Hz, AC only
AC Power Required: UL Rating - Microwave 1.55 kw, 13.0 amps.
UL Rating - Convection 1.55 kw, 13.0 amps.
CSA Rating - Microwave 1.5 kw, 13.0 amps.
CSA Rating - Convection 1.5 kw, 13.0 amps.
Output Power:
Microwave*
Convection Heater
900 watts
1450 watts
Frequency: 2450 MHz
Outside Dimensions: 24 5 /
8
"(W) x 14 7 /
8
"(H) x 19"(D)
Cavity Dimensions: 16 1 /
8
"(W) x 9 5 /
8
"(H) x 16 1 /
8
"(D)
Microwave Oven Capacity:** 1.5 Cu. Ft.
Cooking Uniformity: Turntable system, diameter 15 3 /
8
"
Weight: Approx. 60 lb
* The International Electrotechnical Commission’s standardized method for measuring output wattage. This test method
is widely recognized.
** Internal capacity is calculated by measuring maximum width, depth and height. Actual capacity for holding food is
less.
In compliance with standards set by:
FCC – Federal Communications Commission Authorized.
DHHS – Complies with Department of Health and Human Services (DHHS) rule, CFR, Title 21, Chapter I, Subchapter J.
– This symbol on the nameplate means the product is listed by Underwriters Laboratories, Inc. for use in USA
or Canada.
NHW – Department of National Health and Welfare of Canada.
This microwave oven is listed by the Canadian Standard Association as certified.
