11 E E E 11 E
Pr
oduct Contr
ols
MICROWAVE OVEN PARTS
Part Names
1 Ventilation openings (Rear side)
2 Oven door with see-through window
3 Oven light
It will light when the door is opened or
when oven is in operation.
4 Turntable support
5 Removable turntable
The turntable will rotate clockwise or
counterclockwise.
6 Safety door latches
The oven will not operate unless the
door is securely closed.
7 Waveguide cover:
DO NOT REMOVE.
8 Door open button
9 Auto-Touch control panel
10 Lighted digital display
11 Convection air openings
12 Removable low rack (Broiling rack)
13 Removable high rack (Baking rack)
14 Turntable motor shaft
15 Serial plate
Top
ACCESSORIES
The following accessories are designed especially for use in this oven only for convec-
tion, mix or broil cooking. DO NOT USE FOR MICROWAVE ONLY COOKING. Do not
substitute similar types of racks for these specially designed ones.
High rack (Baking rack)–for convection and low mix.
• This rack is placed on the turntable for two-level cooking, such as layer cakes,
muffins, etc.
Low rack (Broiling rack)–for convection, broiling or high mix.
• Place on the turntable and use for roasting or broiling to allow juices to drain
away from food.
