Chapter 6 : LCD FUNCTIONS DESCRIPTION (continued) HD SCAN™
PAGE 12
3 [IMAGE MENU] + ENTER.
3-1 [flicker filter] + ENTER.
Select one of the 8 levels of the anti flicker with  and validate with ENTER.
3-2 [Black Level] + ENTER.
Adjust the Black level with  + ENTER.
3-3 [RGB Levels] + ENTER.
Select a color with  + ENTER and adjust the level with  + ENTER.
3-4 [under/over] + ENTER.
Select an item with  + ENTER.
• [underscan] = the output image is full screen.
• [overscan] = the output is 10% bigger than in underscan mode.
3-5 [H. smooth] + ENTER.
Select an item with  + ENTER.
• [ON] = active the horizontal filter.
• [OFF] = inactive the horizontal filter.
3-6 [position status] + ENTER.
Displays the image position status.
3-7 [zoom status] + ENTER.
Displays the image zoom status.
3-8 [preset] + ENTER.
This function allows to set all the image parameters (flicker filter, Black level, RGB level, under/overscan, position
& size) to the factory settings.
4
[CONTROL MENU] + ENTER.
4-1 [panel locking] + ENTER.
This function allows to lock the front panel buttons. Select an item with  + ENTER.
• [lock] = allows to lock the front panel push button.
• [unlock] = doesn't lock the front panel button.
NOTE: To unlock push simultaneously on ENTER and EXIT.
4-2 [version] + ENTER.
Status of the internal firmware: xxxx xxxx xxxx.
4-3 [freeze mode] + ENTER.
Select a mode corresponding to your application with  + ENTER.
• [slow] = input source with static picture.
• [fast] = input source with motion picture.
NOTE: This function act on the front panel FREEZE button.
4-4 [erase memories] + ENTER.
This function allows to erase all the image settings memorized.
4-5 [default value] + ENTER.
This function allows to clear the following adjustments and set them to factory value:
FUNCTION POSITION FUNCTION POSITION
1-2 Genlock H Ph 0 3-2 Black level. 0
1-3 SOG input no. 3-3 RGB levels. 0
1-4 H sync load Hi-Z. 3-4 under/overscan underscan.
2-2 Output format 1080i @ 59.94 Hz. 3-5 H smooth off.
2-3 Output rate internal. 4-1 panel locking unlock.
2-4 Sync type tri-levels. 4-2 freeze mode slow.
2-5 test pattern no. Position & Size 0
3-1 Flicker Filter level 1. Zoom 100 %.
