Chapter 6 : LCD FUNCTIONS DESCRIPTION
1 [INPUT MENU] + ENTER.
1-1 [input status] + ENTER.
Displays the input status.
• [INPUT]: [XGA] = input format.
[60 Hz] = input frame frequency.
• [GENLOCK]: [none] = genlock signal not detected.
1-2 [Genlock H. ph.] + ENTER.
This function allows to adjust the genlock horizontal phase. Adjust with  + ENTER.
1-3 [SOG input] + ENTER.
Select [yes] if your input signal is in RGsB (SOG), and valid with ENTER.
1-4 [H sync load] + ENTER.
Select the Horizontal sync load of your input signal with  + ENTER.
2 [OUTPUT MENU] + ENTER.
2-1 [output status] + ENTER.
Displays the output status.
2-2 [output format] + ENTER.
Select one of the following format with  + ENTER:
• 720p @ 59.94 Hz.
• 720p @ 60 Hz.
• 1035i @ 59.94 Hz.
• 1035i @ 60 Hz.
• 1080i @ 50 Hz.
• 1080i @ 59.94 Hz.
• 1080i @ 60 Hz.
2-3 [output rate] + ENTER.
Select one of the following functions with  + ENTER.
• [internal] = The output format depends of the selected output format in LCD menu # 2-2.
• [genlock] = The output format is synchronized onto the genlock input format.
NOTE: To synchronized the XTD920-HDAG (analog genlock version), onto a 1035i or 1080i
format, you should select first the needed format (1035i or 1080i) with the LCD menu #
2-2, and then select [genlock] with the LCD menu # 2-3.
2-4 [sync type] + ENTER.
Select one of the following sync type with  + ENTER.
• [tri-level] = tri-level sync.
• [bi-level] = bi-level sync.
2-5 [test pattern] + ENTER.
Select one item with  + ENTER.
• [yes] = displays a test pattern onto the output.
• [no] = turns OFF the test pattern.
