• Remove all packing materials from the inside and outside of the appliance. Do not remove the
cardboard mica sheet covering the magnetron.
• Check the appliance for damage before using, such as a misaligned or bent door, damaged door
seals, broken or loose door hinges or latches, or dents inside the cavity or on the door. If there is any
damage to the appliance, do not use it, return it to its point of purchase or contact consumer care.
• The mounting surface must be capable of supporting the cabinet load in addition to the added weight
of this microwave, approximately 22.6 - 31.7 kg (50 - 70 pounds), plus additional oven loads of up to
22.6 kg (50 pounds) for a total weight of 45.2 - 54.3 kg (100 - 120 pounds).
• This appliance cannot be installed in cabinet arrangements such as an island or peninsula. It must be
mounted to both a top cabinet and a wall.
• Do not clean this appliance with or use near combustible materials.
• Do not block any ventilation openings on the appliance.
INSTALLATION INSTRUCTIONS
PARTS INCLUDED
PART QTY
Mounting
plate
1
Exhaust
adapter
1
TOP CABINET TEMPLATE Top cabinet
template
1
REA R WALL TEMPLATE Rear wall
template
1
Extra grease
fi lters
2
INSTALLATION ACCESSORIES
PART QTY
Wood screw
(1/4” x 2”)
2
Wing nut 2
Machine screw
(3/16” x 3”)
2
Self aligning
machine screw
(1/4”-20 x 3”)
2
Nylon grommet
(for metal cabinets)
1
Washer 2
Sheet metal screw 2
• Do not operate the appliance without the glass
tray, roller support and shaft in their correct
positions.
• Make sure the shelf is positioned properly inside
the microwave to prevent damage from arcing.
Do not use the microwave with the shelf on the
fl oor of the microwave. Do not use the shelf
when cooking popcorn. Always use pot holders
when removing the shelf as it may be hot.
4
