UTILISATION DU MODÈLE D’INSTALLATION
Il existe trois types d’armoires différents qui
modifi eront la façon dont le modèle de mur arrière
doit être utilisé pour déterminer où installer le
support de montage.
1. Armoire à fond plat :
Le haut du gabarit doit
être aligné avec le bas de l’armoire.
2. Armoire encastrée encadrée :
le haut du
gabarit doit être aligné avec le cadre arrière du
bas de l’armoire.
3. Armoire inférieure encastrée encadrée avec
porte-à-faux avant :
Le haut du gabarit doit être
aligné avec le porte-à-faux avant. Il peut être
utile de mesurer le surplomb, puis de mesurer la
même distance à partir du bas de l’armoire et
de marquer cet endroit.
4. Alignement de la ligne médiane du gabarit
du mur arrière :
Mesurez l’espace où le four
à micro-ondes sera installé et trouvez la ligne
médiane. Marquez cette ligne avec un crayon
et une règle droite. Alignez la ligne centrale du
gabarit avec la ligne centrale sur le mur.
